2. Install Handlebar & Smartbar Box
Use a 5mm hex wrench to loosen
the clamping screw on the top
tube of the fork.
Remove the fork protection
hose and cover, keeping the
clamping screw (M6 x 30mm)
for later use.
The protection hose and top
cover are only for packaging
and not for assembly.
Insert the handlebar stem into the fork's top tube.
Notice
Two 15mm stem spacers are provided to install as needed.
2.1 2.2
2.3
10
