USB 7132 / 7133 / 7134

Professional Power Amplifier

OUTPUT

Stereo mode

Output binding post connection

Bridged mono mode

Output binding post connection

Note : if single channel input , it can

also work , but the input sensitivity

will be 1.4 times lower than that of

both channel inputs .

Stereo mode

Speakon output connection

Speaker+ to PIN 1+

Speaker- to PIN 1-
