US endoscopy Co2mpact Endoscopic Insufflator - Page 36

CO
2
MPACT ENDOSCOPIC INSUFFLATOR
®
SYSTEM Operator’s Manual
Page 36
Table 2
Guidance and manufacturer’s declaration – electromagnetic immunity
The CO
2
MPACT ENDOSCOPIC INSUFFLATOR
®
SYSTEM is intended for use in the electromagnetic
environment specified below. The customer or the user of the CO
2
MPACT ENDOSCOPIC INSUFFLATOR
®
SYSTEM should assure that it is used in such an environment.
Immunity Test
IEC 60601
test level
Compliance level
Electromagnetic environment –
guidance
IEC 61000-4-2
Floors should be wood, concrete or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30 %.
Electrostatic
discharge (ESD)
+/-8 KV contact
+/-8 KV contact
+/-2 KV, +/-4 KV, +/-8
KV, +/-15 KV air
+/-2 KV, +/-4 KV, +/-8
KV, +/-15 KV air
IEC 61000-4-4
Mains power quality should be that of a
typical commercial or hospital
environment.
Electrical fast
transient burst
+/-2 KV
+/-2 KV
100 kHz
100 kHz
IEC 61000-4-5
Mains power quality should be that of a
typical commercial or hospital
environment.
Surge
+/-.5 KV, +/-1 KV
differential
+/-.5 KV, +/-1 KV
differential
mode
Mode
+/-.5 KV, +/-1 KV, +/-2
KV common mode
+/-.5 KV, +/-1 KV, +/-2
KV common mode
IEC 61000-4-11
Mains power quality should be that of a
typical commercial or hospital
environment. If the user of the
CO
2
MPACT ENDOSCOPIC
INSUFFLATOR
®
SYSTEM requires
continued operation during power mains
interruptions, it is recommended that the
CO
2
MPACT ENDOSCOPIC
INSUFFLATOR
®
SYSTEM be powered
from an uninterruptible power supply or
battery.
Voltage dips
0 % Ut
0 % Ut
(>95 % dip in Ut)
(>95 % dip in Ut)
0º, 45º, 90º, 135º, 180º,
225º, 270º, 315º
0º, 45º, 90º, 135º, 180º,
225º, 270º, 315º
for 0.5 cycle
for 0.5 cycle
0 % Ut
0 % Ut
(>95 % dip in Ut)
(>95 % dip in Ut)
for 1 cycle
for 1 cycle
70 % Ut
70 % Ut
(30% dip in Ut)
(30% dip in Ut)
for 25 cycles
for 25 cycles
Short interruptions and
voltage variations on
power supply input
lines
0 % Ut for 250 cycles
0 % Ut for 250 cycles
IEC 61000-4-8
Power frequency magnetic fields should
be at levels characteristic of a typical
location in a typical commercial or
hospital environment.
Power frequency
(50/60 Hz)
magnetic field
30 A/m
30 A/m
50 Hz
50 Hz
Note: Ut is the A.C. mains voltage prior to application of the test level.
