2LV/2L1/2L2/2MS/2MT
2-1-2
(2) MP tray paper feed section
The MP tray can contain 100 sheets. Feeding from the MP tray is performed by the rotation of the MP paper
feed roller. Also, function of the MP separation pad prevents paper from multiple feeding.
Figure 2-1-3 MP tray paper feed section
Figure 2-1-4 MP tray paper feed section block diagram
1
3 4
6
52
1. MP paper feed roller
2. MP separation pad
3. MP bottom plate
4. MP frame
5. MP base
6. MP (Multi purpose)tray
YC4-1
YC4-2
YC4-3
YC4-4
YC8-2
MMOTCW
MMOTRDYN
MMOTCLKN
MMOTONN
MPFSLN
6
MM 5
4
3
MPSOL
EPWB
YC2-12
YC8-3
R-LPWB
MPFSENS
MPPS
MPFSENS
