Vacon 100 flow Applications Manual

Fault
code
Fault ID Fault name Possible cause How to correct the fault
101 1101 Feedback supervision
fault (PID1)
The PID controller: the feed-
back value is not in the
supervision limits (P3.13.6.2
and P3.13.6.3) and the delay
(P3.13.6.4), if you set the
delay.
Do a check of the process.
Do a check of the parameter set-
tings, the supervision limits and
the delay.
105 1105 Feedback supervision
fault (ExtPID)
The external PID controller:
the feedback value is not in
the supervision limits
(P3.14.4.2 and P3.14.4.3)
and the delay (P3.14.4.4), if
you set the delay.
109 1109 Input pressure super-
vision
The supervision signal of the
input pressure (P3.13.9.2) is
lower than the alarm limit
(P3.13.9.7).
Do a check of the process.
Do a check of the parameters in
menu M3.13.9.
Do a check of the input pressure
sensor and connections.
1409 The supervision signal of the
input pressure (P3.13.9.2) is
lower than the fault limit
(P3.13.9.8).
111 1315 Temperature fault 1 1 or more of the tempera-
ture input signals (set in
P3.9.6.1) is higher than the
alarm limit (P3.9.6.2).
Find the cause of the temperature
rise.
Do a check of the temperature
sensor and connections.
If no sensor is connected, make
sure that the temperature input is
hardwired.
See the option board manual for
more information.
1316 1 or more of the tempera-
ture input signals (set in
P3.9.6.1) is higher than the
fault limit (P3.9.6.3).
112 1317 Temperature fault 2 1 or more of the tempera-
ture input signals (set in
P3.9.6.5) is higher than the
fault limit (P3.9.6.6).
1318 1 or more of the tempera-
ture input signals (set in
P3.9.6.5) is higher than the
fault limit (P3.9.6.7).
113 1113 Pump running time In the Multi-pump system, 1
or more of the pump run-
time counters is above a
user-specified alarm limit.
Do the necessary maintenance
actions, reset the runtime counter
and reset the alarm. See Pump
running time counters.
1313 In the Multi-pump system, 1
or more of the pump run-
time counters is above a
user-specified alarm limit
VACON · 378 FAULT TRACING
11
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
