NAME：VADANIA PUSH TO OPEN DRAWER SLIDES VF1245
MATERIAL: COLD-ROLLED （COLD ROLLED） STEEL
INSTALLATION METHOD: SIDE MOUNT
MAXIMUM LOAD CAPACITY: 100LB / 45KG.
MINI DEPTH OF CABINET: DRAWER LENGTH + 0.12IN / 3MM
SURFACE TREATMENT: GALVANIZED / CHROME
SLIDE STYLE: 3 FOLDS FULL EXTENSION, SIDE MOUNT, SEPARABLE
PLATE THICKNESS: OUTER SLIDER 0.04IN(1.2MM) / MIDDLE SLIDER
0.04IN(1.2MM) / INNER SLIDER 0.06IN(1.5MM)
SIZE: 10-24IN / 250-600MM
SCOPE OF APPLICATION: &,9,/)851,785(2ႈ&()851,785(
KITCHEN CABINETS/WARDROBES, ETC
A
A
C
Visible hole for screwing
B
' 2GZKXGRGJP[YZSKTZNURKŐSSȕ
( <KXZOIGRGJP[YZSKTZNURKŐSSȕ
) ,O^NURKŐSSȕ
'B(LUXLO^OTMGTJGJP[YZOTM)UTR_LUXLO^OTM
:NKVXUJ[IZNGYGYZXUTM[TO\KXYGRJKYOMTGRRZNK'()NURKYIGTHKOT-
YZGRRKJYIXK]Y
<'*'4/'9IXK]YŐSSȕ
9[OZGHRKLUX'()
