Vaillant VIH R /3 R Series Safety Instructions

Appendix
10
Safety instructions 0020241666_01
VIH SW 400/3
BR
VIH SW 500/3
BR
VIH SW 400/3
MR
VIH SW 500/3
MR
Heating coil surface (heating
circuit)
3.2 m² 4.4 m² 3.2 m² 4.4 m²
Volume of domestic hot wa-
ter at 40 C (V₄₀) (heating cir-
cuit)
386 l 471 l 386 l 471 l
Heating coil pressure loss
(solar circuit/environment
circuit)
0.0021 MPa 0.0027 MPa 0.0021 MPa 0.0027 MPa
Heating coil surface (solar
circuit)
1.5 m² 2.1 m² 1.5 m² 2.1 m²
Volume of domestic hot wa-
ter at 40 C (V₄₀) (solar circuit)
606 l 771 l 606 l 771 l
Net weight
189 kg 249 kg 203 kg 265 kg
Weight filled ready for opera-
tion
561 kg 703 kg 575 kg 719 kg
Technical data – Electrics
VIH R 300/3
MR
VIH R 400/3
MR
VIH R 500/3
MR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Electrical connection for the
power supply unit
230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz
IP rating
XX XX XX XX XX XX
VIH S 300/3
MR
VIH S 400/3
MR
VIH S 500/3
MR
VIH SW 400/3
MR
VIH SW 500/3
MR
Electrical connection for the
power supply unit
230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz
IP rating
XX XX XX XX XX
Technical data – Material
VIH R 300/3
BR
VIH R 400/3
BR
VIH R 500/3
BR
VIH R 300/3
MR
VIH R 400/3
MR
VIH R 500/3
MR
Cylinder material
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Corrosion protection
Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Insulation material
Polyurethane Polyurethane Polyurethane Polyureth-
ane + vacuum
panel
Polyureth-
ane + vacuum
panel
Polyurethane
+ vacuum
panel
Insulation thickness
75 mm 70 mm 70 mm 95 mm 100 mm 100 mm
Propellant for insulating ma-
terial
HFO-
1233zd(E)
HFO-
1233zd(E)
HFO-
1233zd(E)
1233zd(E) 1233zd(E) 1233zd(E)
Ozone depletion potential
ODP
WP 1 WP 1 WP 1 WP 1 WP 1 WP 1
VIH RW 300/3
BR
VIH RW 400/3
BR
VIH RW 500/3
BR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Cylinder material
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Black steel
(S235JR)
Corrosion protection
Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
magnesium
protection an-
ode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Enamel with
external cur-
rent protection
anode
Insulation material
Polyurethane Polyurethane Polyurethane Polyureth-
ane + vacuum
panel
Polyureth-
ane + vacuum
panel
Polyurethane
+ vacuum
panel
Insulation thickness
75 mm 70 mm 70 mm 95 mm 100 mm 100 mm
