Appendix
12
Safety instructions 0020241666_01
VIH R 300/3
BR
VIH R 400/3
BR
VIH R 500/3
BR
VIH R 300/3
MR
VIH R 400/3
MR
VIH R 500/3
MR
Continuous domestic hot
water output (heating circuit)
(60 °C 35 K)
611 l/h 668 l/h 936 l/h 611 l/h 668 l/h 936 l/h
Continuous domestic hot
water output (heating circuit)
(70 °C 35 K)
827 l/h 904 l/h 1,268 l/h 827 l/h 904 l/h 1,268 l/h
Continuous domestic hot
water output (heating circuit)
(80 °C 35 K)
1,035 l/h 1,130 l/h 1,586 l/h 1,035 l/h 1,130 l/h 1,586 l/h
Domestic hot water output
(50 °C)
342 l/10 min 520 l/10 min 536 l/10 min 342 l/10 min 520 l/10 min 536 l/10 min
Domestic hot water output
(55 °C)
371 l/10 min 459 l/10 min 587 l/10 min 371 l/10 min 459 l/10 min 587 l/10 min
Domestic hot water output
(60 °C)
396 l/10 min 517 l/10 min 623 l/10 min 396 l/10 min 517 l/10 min 623 l/10 min
Domestic hot water output
(65 °C)
439 l/10 min 528 l/10 min 644 l/10 min 439 l/10 min 528 l/10 min 644 l/10 min
Domestic hot water output
(70 °C)
451 l/10 min 530 l/10 min 662 l/10 min 451 l/10 min 530 l/10 min 662 l/10 min
Specific flow rate Delta
(50 °C 30 K)
39.9 l/min 49.0 l/min 62.5 l/min 39.9 l/min 49.0 l/min 62.5 l/min
Specific flow rate Delta
(55 °C 30 K)
43.3 l/min 53.6 l/min 68.5 l/min 43.3 l/min 53.6 l/min 68.5 l/min
Specific flow rate Delta
(60 °C 30 K)
46.2 l/min 60.3 l/min 72.7 l/min 46.2 l/min 60.3 l/min 72.7 l/min
Specific flow rate Delta
(65 °C 30 K)
51.2 l/min 61.6 l/min 75.1 l/min 51.2 l/min 61.6 l/min 75.1 l/min
Specific flow rate Delta
(70 °C 30 K)
52.6 l/min 61.8 l/min 77.2 l/min 52.6 l/min 61.8 l/min 77.2 l/min
Nominal heating medium
volume flow for the heating
circuit
1.81 m³/h 1.93 m³/h 2.79 m³/h 1.81 m³/h 1.93 m³/h 2.79 m³/h
Technical data – VIH RW output
VIH RW 300/3
BR
VIH RW 400/3
BR
VIH RW 500/3
BR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Output characteristic figure
NL (50 °C)
3.3 5.5 8.1 3.3 5.5 8.1
Output characteristic figure
NL (55 °C)
3.6 5.9 8.7 3.6 5.9 8.7
Output characteristic figure
NL (60 °C)
3.8 6.1 8.9 3.8 6.1 8.9
Output characteristic figure
NL (65 °C)
3.8 6.1 8.9 3.8 6.1 8.9
Output characteristic figure
NL (70 °C)
3.8 6.1 8.9 3.8 6.1 8.9
Continuous domestic hot
water output (heating circuit)
(50 °C 35 K)
26.7 kW 38.3 kW 51.0 kW 26.7 kW 38.3 kW 51.0 kW
Continuous domestic hot
water output (heating circuit)
(55 °C 35 K)
35.5 kW 51.0 kW 68.0 kW 35.5 kW 51.0 kW 68.0 kW
Continuous domestic hot
water output (heating circuit)
(60 °C 35 K)
43.2 kW 62.2 kW 83.0 kW 43.2 kW 62.2 kW 83.0 kW
Continuous domestic hot
water output (heating circuit)
(50 °C 35 K)
656 l/h 941 l/h 1,255 l/h 656 l/h 941 l/h 1,255 l/h
Continuous domestic hot
water output (heating circuit)
(55 °C 35 K)
872 l/h 1,254 l/h 1,672 l/h 872 l/h 1,254 l/h 1,672 l/h
