Appendix
14
Safety instructions 0020241666_01
VIH S 300/3
BR
VIH S 400/3
BR
VIH S 500/3
BR
VIH S 300/3
MR
VIH S 400/3
MR
VIH S 500/3
MR
Domestic hot water output
(60 °C)
161 l/10 min 219 l/10 min 223 l/10 min 161 l/10 min 219 l/10 min 223 l/10 min
Domestic hot water output
(65 °C)
166 l/10 min 234 l/10 min 237 l/10 min 166 l/10 min 234 l/10 min 237 l/10 min
Domestic hot water output
(70 °C)
177 l/10 min 258 l/10 min 261 l/10 min 177 l/10 min 258 l/10 min 261 l/10 min
Specific flow rate Delta
(50 °C 30 K)
16.8 l/min 22.3 l/min 22.3 l/min 16.8 l/min 22.3 l/min 22.3 l/min
Specific flow rate Delta
(55 °C 30 K)
17.5 l/min 23.7 l/min 24.2 l/min 17.5 l/min 23.7 l/min 24.2 l/min
Specific flow rate Delta
(60 °C 30 K)
18.8 l/min 25.6 l/min 26.0 l/min 18.8 l/min 25.6 l/min 26.0 l/min
Specific flow rate Delta
(65 °C 30 K)
19.4 l/min 27.3 l/min 27.7 l/min 19.4 l/min 27.3 l/min 27.7 l/min
Specific flow rate Delta
(70 °C 30 K)
20.7 l/min 30.1 l/min 30.5 l/min 20.7 l/min 30.1 l/min 30.5 l/min
Nominal heating medium
volume flow for the heating
circuit
0.989 m³/h 1.20 m³/h 1.20 m³/h 0.989 m³/h 1.20 m³/h 1.20 m³/h
Nominal heating medium
volume flow for the solar
circuit
1.81 m³/h 1.93 m³/h 2.79 m³/h 1.81 m³/h 1.93 m³/h 2.79 m³/h
Technical data – VIH SW output
VIH SW 400/3
BR
VIH SW 500/3
BR
VIH SW 400/3
MR
VIH SW 500/3
MR
Output characteristic figure
NL (50 °C)
1.2 2.2 1.2 2.2
Output characteristic figure
NL (55 °C)
1.4 2.5 1.4 2.5
Output characteristic figure
NL (60 °C)
1.5 2.8 1.5 2.8
Output characteristic figure
NL (65 °C)
2.0 3.0 2.0 3.0
Output characteristic figure
NL (70 °C)
2.0 3.0 2.0 3.0
Continuous domestic hot
water output (heating circuit)
(50 °C 35 K)
27.4 kW 38.2 kW 27.4 kW 38.2 kW
Continuous domestic hot
water output (heating circuit)
(55 °C 35 K)
36.4 kW 51.0 kW 36.4 kW 51.0 kW
Continuous domestic hot
water output (heating circuit)
(60 °C 35 K)
44.3 kW 62.2 kW 44.3 kW 62.2 kW
Continuous domestic hot
water output (heating circuit)
(50 °C 35 K)
674 l/h 941 l/h 674 l/h 941 l/h
Continuous domestic hot
water output (heating circuit)
(55 °C 35 K)
896 l/h 1,253 l/h 896 l/h 1,253 l/h
Continuous domestic hot
water output (heating circuit)
(60 °C 35 K)
1,091 l/h 1,530 l/h 1,091 l/h 1,530 l/h
Domestic hot water output
(50 °C)
213 l/10 min 264 l/10 min 213 l/10 min 264 l/10 min
Domestic hot water output
(55 °C)
239 l/10 min 297 l/10 min 239 l/10 min 297 l/10 min
Domestic hot water output
(60 °C)
266 l/10 min 330 l/10 min 266 l/10 min 330 l/10 min
Domestic hot water output
(65 °C)
292 l/10 min 363 l/10 min 292 l/10 min 363 l/10 min
