Output clipping limit
Error level
(V)
Scaled output
range:
0 ... 10 V
0 ... 100 %RH
Figure 10 Overrange Behavior of Relative Humidity Measurement
The transmitter may measure humidities in excess of 100î%RH if the sensor
element becomes wet due to condensation.
Safety
The GMW80 series transmitter delivered to you has been tested for safety and
approved as shipped from the factory. Note the following precautions:
Connect only de-energized wires.
Do not modify the unit. Improper modification can damage the
product or lead to malfunction.
Electrostatic Discharge (ESD) can cause immediate or latent
damage to electronic circuits. Avoid touching exposed
component contacts during installation and maintenance.
15
2 Product Overview
