Device Object
Table 19 below describes the properties of the device object. Note the
following:
- Writable means writable via BACnet
- Max_Master and Max_Info_Frames are required in a Master device.
- UV = Configured at Vaisala factory to a unique value. See additional
information after the table.
Table 19 Device Object Properties
Property
Data type
(Application Type)
Writable
(Conforma
nce Code)
Value or Initial Value
Persistence
Object_Identifier
BACnetObjectIdentifier
Y (R)
02 00 00 00 (hex)
Object Type = 8,
Instance = xxxxxxx UV
Nonvolatile
Object_Name
CharacterString[50]
Y (R)
"HMW90_Yxxxxxxx" UV
Nonvolatile
Object_Type
BACnetObjectType
(ENUMERATED)
N (R)
8 (Device Object)
Fixed
System_Status
BACnetDeviceStatus
(ENUMERATED)
N (R)
0 (Operational)
Volatile
Vendor_Name
Character String
N (R)
"Vaisala Oyj"
Fixed
Vendor_Identifier
Unsigned16
N (R)
339
Fixed
Model_Name
CharacterString
N (R)
"HMW95"
Nonvolatile
Firmware_Revision
CharacterString
N (R)
X.X.X.X (BACnet
interface)
Fixed
Application_Software
_Revision
CharacterString
N (R)
X.X.X.X
Fixed
Location
Character String[50]
Y (O)
“Location”
Nonvolatile
Description
Character String[50]
Y (O)
“Description”
Nonvolatile
Protocol_Version
Unsigned
N (R)
1
Fixed
Protocol_Revision
Unsigned
N (R)
4
Fixed
Protocol_Services
BACnetProtocolServic
es Supported (BIT
STRING)
N (R)
Read Property
Read Property Multiple
Write Property
Device Communication
Control
Reinitialize Device
Who-Is
Who-Has
Fixed
Protocol_Object_Typ
es_Supported
BACnetObjectTypesSu
pported (BIT STRING)
N (R)
Analog Input
Analog Value
Device
Fixed
