Table 65 Example Flag Values With Acceptance Criteria Combinations
Value Criteria
FFFF All Pass (Thresholds disabled)
0000 All Fail (No data are passed)
AAAA LOG
8888 LOG and CSR
A0A0 LOG and SQI
8080 LOG and CSR and SQI
F0F0 SQI
FAFA SQI or LOG
C0C0 SQI and CSR
F000 SQI and SIG
C000 SQI and SIG and CSR
FFF0 SQI or SIG
CCC0 (SQI or SIG) and CSR
One way to generate these values is to imagine four 16-bit quantities having the following
names and values: LOG=AAAA, CSR=CCCC, SQI=F0F0, SIG=FF00. The flag value needed
to represent a given logical combination of threshold outcomes is obtained as the result
when that same logical combination is applied to these special numbers.
For example:
(SQI or SIG) and CSR = (F0F0 or FF00 ) and CCCC
= (FFF0) and CCCC
= CCC0
which corresponds with one of the examples given above.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
---------------------------------------------------------------
| | | | | | | | | | | | | | | | |
| Threshold Control Flags for Corrected Reflectivity | Input 12
|---------------------------------------------------------------|
See description for Input 11.
