15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
---------------------------------------------------------------
| | | | | | | | | | | | | | | | |
| SQI Threshold in 1/16 of dB(SOPRM Input 6) | Input 6
|---|---|---|---|---|---|-------|----|---------------------------|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
---------------------------------------------------------------
| | | | | | | | | | | | | | | | |
| Weather Signal Power Threshold in 1/16 of dB(SOPRM Input 7) | Input 7
|---|---|---|---|---|---|-------|----|---------------------------|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
---------------------------------------------------------------
| | | | | | | | | | | | | | | | |
| Threshold Control Flags(SOPRM Input 11,12,13,14,19) | Input 8
|---|---|---|---|---|---|-------|----|---------------------------|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
---------------------------------------------------------------
| | | | | | | | | | | | | | | | |
| <spare> | Input 9
|----------------------------------------------------------------|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
---------------------------------------------------------------
| | | | | | | | | | | | | | | | |
| <spare> | Input 10
|----------------------------------------------------------------|
8.31
Set Task Identification Information
(TASKID)
TASKID allows you to name the (I,Q) data that are currently being acquired by RVP900.
This naming information then becomes associated with these data, and is available in the
pulse information structures (struct rvp900PulseInfo) that are read from the
Timeseries API. The iAqMode
field of the pulse headers (struct rvp900PulseHdr)
are incremented each time a TASKID opcode is received, but the continuous flow of (I,Q)
data from the RVP900/Rx card(s) are disturbed.
