Consideration Description
Power module The power module is an auto-ranging AC-DC converter generating 24V to drive the RVP901
and external fans.
The RVP901 IFDR is delivered with the power supply module attached to the IFDR
mechanical housing.
You can remove the power supply module and mount it nearby in the radar cabinet.
The power supply, fans, and bracket add 8.4 cm (3.3 in) of overall width to the receiver
module.
Power modules are available for 100 ... 240 VAC at 47 ... 63 Hz or 18 ... 36 VDC. The AC
power supply is a low noise, low ripple, auto-switching unit. The DC input voltage may be
unregulated.
If DC voltage is selected as an option, 3 fan assemblies are available. These fan options allow
DC voltages from 12 ... 18 VDC and 18 ... 28 VDC.
The IFDR has an internal regulator to supply the digital circuits the voltages need. The
internal regulated power modules are sized to provide several Watts more than is required
by RVP901. A ferrite choke around the supply wires, near the terminal strip, is also
recommended.
For information on the power harness needed to supply power to the RVP901 and fans, see
9.4 RVP901 IFDR Specifications (page 331) and B. RVP901 IFDR Technical Drawings
(page 369).
4.2.3
RVP901 IFDR I/O Connectors
Table 14 RVP901 Connector Panel Summary
J-ID Label Type Description
J1
DC IN MINIFIT 2X2 Power Supply Input
J2
ETHERNET RJ-45 Ethernet connection to host computer
J3
MISC I/O-B 51-Pin
Micro-D
Each Micro-D has an identical pinout
J4
UP LINK RJ-45 Gigabit serial Link
J5
DN LINK RJ-45 Same as J4
J6
MISC I/O-A 51-Pin
Micro-D
Same as J3
J7
CLK IN SMA Reference Clock Input
J8
TRIG-B SMA General purpose trigger I/O
J9
CLK OUT SMA Reference Clock Output
J10
DDS SMA Direct Digital Synthesizer Output
J11
TxDAC-B SMA Direct Transmit IF output
J12
TxDAC-A SMA Same as J11
J13A
ADC-A SMA Direct IF Input. IF-1 for single channel or primary polarization
J13B
ADC-B SMA Direct IF Input. IF-2 for secondary polarization
Chapter 4 – RVP Hardware
57
