1 DA5816900SR 1 Air Motor Assembly
2A CH210110 1 Spring
2BB ★ 1 Ball Seal
2CC ★ 1 O-Ring
2D ★ 2 Ball Seat
2DD CF318028 4 Cap Screw
2E ★ 2 Ball
2EE ★ 1 Conical Spring
2FF ★ 1 Filter
2G CH411013 1 Ball Guide
2H ★ 1 Ball
2HH DC1563013 1 Ball Guide
2L CH202950SR 1 Relief Valve Assy. (PA133 & PA135) 4
(incl. items 9, 10, 14)
2L CH207950SR 1 Relief Valve Assy. (PA136) 4
(incl. items 9, 10, 14)
2N DA2686299SR 1 Coupling V-Retainer
2Z ★ 1 Gasket
5 A8009108SR 1 Washer (PA133) (incl. items 2A, 8, 52)
5 DA1221108SR 1 Washer (PA135) (incl. items 2A, 8, 52)
5 A8015108SR 1 Washer (PA136) (incl. items 2A, 8, 52)
6 DA5290900SR1 1 Release Guide Assembly 2
(incl. items 2BB, 2DD, 2EE, 2Z, 10)
7 CH203950SR 1 Hydraulic Cylinder Assy (PA133, 7001) 5
(incl. items 2D, 2E, 8, 10)
7 DA1227950SR 1 Hydraulic Cylinder Assembly (PA135) 5
(incl. items 2D, 2E, 8, 10)
7 CH208950W 1 Hydraulic Cylinder Assembly (PA136) 5
(incl. items 2D, 2E, 8, 10)
8 CB180040 1 Plunger (PA133)
8 DA1219040 1 Plunger (PA135)
8 CB185040 1 Plunger (PA136)
9 ★ 1 Ball Seat
10 ★ 4 Gasket
11 CL166950SR 1 Hydraulic Body Assembly
14 ★ 1 Plug
19 ★ 1 Back-Up Washer
24 CF692950W 1 Coupler Assembly 3
(incl. items 2D, 2G, 2H, 10)
26 CB108005SR 1 Base
27 B1320028 2 Screw
29 CB241218W 1 Treadle
31 CF180900SR 1 Reservoir Assembly
32 CL164950SR 1 Reservoir Cap (incl. item 19, 53)
34 DA5015118SR 1 Filter Kit
35 CK352950SR 1 Poppet Guide Assembly
36 CL163950SR1 1 Coupler Kit
52 ★ 1 Rubber Washer
53 ★ 1 O-Ring
54B ♦ 1 Air Piston (new style)
55B ♦ 1 Glyd Ring
56 ♦ 1 O-Ring
★ Indicates items included in and available only as part of Pump Repair Kit PA133K3.
♦ Indicates items included in and available only as part of Air Piston Repair Kit CK354950SR.
NOTE: The back-up washer, Item 19 (B1014565) may be purchased separately from Pump Repair Kit PA133K3.
Filter Assembly (DA5015118SR) is available as a separate item.
NOTE: Changes have been made in the design of the shuttle piston, end cover, and air cylinder that improve air motor
performance. The new parts will not work when used with the existing old-style parts. If one of these parts requires
replacement, a complete new air motor (DA5816900SR) must be used.
Repair Parts List for Figure 1
Item Part Number Qty. Description Fig. No.
