Part numbers marked with an asterisk (*) are contained in a Repair Kit
see sheet 6 of 6 for individual repair kit information.
NOTE:
Standard relief valves are set at 10,100/10,700 PSI.
Relief valves pre-set at special settings are available.
Refer to your pump model number or contact Power Team Technical Services.
1 11151 4 Cap Screw
(10-24 UNC X 1-1/4 Lg.;
Torque to 50/60 in. lbs.; For all
except PA6-HUNT)
11151 2 Cap Screw (10-24 UNC X 1-1/4 Lg.;
Torque to 50/60 in. lbs.; For PA6-
HUNT)
2 37199 1 Intake Air Valve Body (For all
except PA6-TAL, IMT200
& PA6-HUNT)
309246 1 Intake Air Valve Body (For PA6-
TAL)
33843 1 Intake Air Valve Body (For
IMT200)
351348 1 Intake Air Valve Body (For PA6M-
ROM)
3*29992 1 Foam Tube (For all except PA6-
HUNT)
15459 1 Muffler (For PA6-HUNT)
4 420965BK2 1 Cover Plate (For all except PA6-2,
PA6-2E, PA6-2N, PA6-2V, PA6A,
PA6AM, PA6M-1, PA6M-2, IMT200,
PA6-HUNT, PA6-LUKAS)
421156BK2 1 Cover Plate (For PA6A & PA6AM)
58688BK2 1 Cover Plate (For PA6M-1, IMT200,
PA6M-1-CAR & PA6M-1-STEL)
58706BK2 1 Cover Plate (For PA6-2, PA-2E,
PA6-2N, PA6-2V, PA6M-2
& PA6-2-FS-LR)
421173BK2 1 Cover Plate (For PA6-LUKAS)
421164BK2 1 Cover Plate (For PA6-HUNT)
59078BK2 1 Cover Plate (For PA6-2-CM)
5 11089 2 Washer (#10 bolt)
6 11435 2 Soc. Hd. Cap Screw (10-24 UNC x
1-3/4 Lg.; Torque to 50/60 in. lbs.;
For all except PA6-HUNT)
11151 2 Cap Screw (10-24 UNC X 1-1/4 Lg.;
Torque to 50/60 in. lbs.; For PA6-
HUNT)
7 58563 1 Release Valve Body (For all except
PA6M-CHIEF, PA6-TAL, PA6-HUNT
& PA6M-PL)
58579 1 Release Valve Body (For PA6M-
CHIEF, PA6-TAL & PA6M-PL)
58817 1 Release Valve Body (For PA6-
HUNT)
58858 1 Release Valve Body (For PA6M-
ROM)
8 11127 1 Pressure Plug (3/8 NPTF; For all
except PA6-KJ, PA6-HUNT & PA6-SS)
11048 1 Plug Fitting (1/8 NPTF; For PA6-
HUNT)
12203 1 Straight Fitting (3/8 NPTF; For PA6-
HUNT)
252343 1 Plug Fitting (1/4 BSP; For PA6M-
ROM)
9 251689 1 Breather/Filler Cap
10 *10273 1 O-ring (13/16 X 5/8 X 3/32; Nitrile; For
all except PA6-2E, PA6-2V, PA6E &
PA6V)
18999 1 O-ring (13/16 X 5/8 X 3/32; Viton; For
PA6-2V & PA6V)
250157 1 O-ring (13/16 X 5/8 X 3/32; EPR; For
PA6-2E & PA6E)
11 64767 1 Pump Body
12 17428 4 Soc. Hd. Cap Screw (1/4-20 UNC
X 3-1/2 Lg.;
Torque to 85/95 in. lbs. oiled.
Note: Cross torque in increments of
30 in. lbs.)
13 18969 1 Tee Fitting (For PA6A & PA6AM)
14 -------- - Relief Valve (When ordering a
replacement relief valve refer to
stamped number on the outside of
the relief valve. See note below.
Apply loctite 592 [Power Team
#905516] or equiv. & torque to
150/170 in. lbs.)
15 253366 1 Tubing Assembly (For PA6A &
PA6AM)
16 16177 1 90° Elbow Fitting (For PA6A &
PA6AM)
19 21046 1 Valve Body (For PA6A & PA6AM)
20 *10495 1 Spring (1/2 O.D. X 1-5/8 Lg.; For
PA6A & PA6AM)
21 22361 1 Valve Body (For PA6A & PA6AM)
22 21306 1 Spring Guide (For PA6A & PA6AM)
23 10263 2 Special Washer (1" X .765 X 1/32;
For PA6A & PA6AM; Note: Apply
Permatex #80019 sealant or equiv.
to both sides of bottom
washer only.)
24 *10268 1 O-ring
(1/2 X 3/8 X 1/16; For PA6A &
PA6AM)
25 21305 1 Valve Cup (For PA6A & PA6AM)
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
Parts List Form No. 101652
Sheet No. 3 of 6
Rev. 35 Date: 29 Mar. 2001
Continued -
To Next Page
