Valcom V-1092 User Manual

2 947092
ONE-WAY
V-1092
One-Way
Page
Control
Unit
AMPLIFIED
T
IN
RRT
OUT
T
R
R
T
1Volt RMS
Max
SPEAKERS
Figure 1.
TECHNICAL ASSISTANCE
When trouble is reported, verify the unit is
properly connected and there are no broken
connections leading to this unit.
Assistance in troubleshooting is available from the
factory. When calling, you should have a VOM
and a test set and call from the job site.
Call (540) 563-2000 and press 1 for
Technical Support or visit our website at
http://www.valcom.com.
VALCOM equipment is not field repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA. Should repairs be necessary,
attach a tag to the unit clearly stating your
company name, address, phone number, contact
person and the nature of the problem. Send the
unit to:
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
WARRANTY
Warranty information may be found on our
website at www.valcom.com/warranty
TABLE 1 - TROUBLESHOOTING CHART
Problems Possible Causes Verifications Possible Solutions
No audio output to
speaker.
Open input path.
Open output path.
Place handset across V-1092
input terminals; No audio
present.
Place handset across speaker
terminal; No audio present.
Check cabling and cross-
connections to V-1092.
Check cabling and cross-
connections from V-1092
to speaker.
