Valcom V-9972 User Manual

4 947573
Function Settings DIP Switch
Output Port Selection (SW 1)
Two output connections are available on the V-9972. The Talkback Page Out connection provides FXO
(loop-start trunk) signaling. The One Way Page Out connection provides a standard tip/ring audio output.
The default level of the One Way Page Out is -10dBm, but can be changed in software to +2.2 dBm for
applications that require the higher output level.
Silence Timeout Selection (SW 2 & 3)
Silence Timeout indicates how many seconds the V-9972 will stay active after the audio input has stopped.
This can be used to disconnect a call after the caller has stopped speaking. Three values are available with
the switch settings; additional options are available in software programming.
SW 2
SW 3
Timeout
OFF
OFF
8 Seconds
OFF
ON
4 Seconds
ON
OFF
2 Seconds
ON
ON
Software control (default: no timeout)
Absolute Timeout Selection (SW 4 & 5)
Absolute Timeout indicates how many seconds the V-9972 will stay active for any caller. When the timeout
setting expires, the call is disconnected. Three values are available with the switch settings; additional
options are available in software programming.
SW 4
SW 5
Timeout
OFF
OFF
128 Seconds
OFF
ON
16 Seconds
ON
OFF
8 Seconds
ON
ON
Software control (default: no timeout)
Input Port Selection (SW 6)
Input Port selects which of the Page Input RJ11 jacks is active. The ports are labeled FXO and FXS to
indicate the type of signaling provided. The FXS port detects off-hook condition and provides dial tone
to the circuit. The FXS port can be used with a standard phone or loop-start trunk port. The FXO port
is a loop-start trunk port and can be used with a Station Port or FXS on a PBX.
SW 1
Talkback Page Out
One Way Page Out
ON
Enabled
Disabled
OFF
Disabled
Enabled
SW 6
Page Input FXS
Page Input FXO
ON
Enabled
Disabled
OFF
Disabled
Enabled
