Valcom V-9972 - Connection Diagrams; Connections for Self-Amplified Speakers or External Amplifier; Connections for Multi-Zone Controllers

6 947573
CONNECTIONS TO SELF-AMPLIFIED SPEAKERS OR EXTERNAL AMPLIFIER
VP-624D
SUPPLY*
POWER
-24VDC
OTHER
SUPPLY
POWER
-
+
OR
SOURCE
MUSIC
LEVEL
LOW
*MAY BE PROVIDED
BY PAGE CONTROL.
FXS PORT
OR PBX STATION PORT.
(DIP SWITCH SW6 OFF)
ANALOG TELEPHONE
OR PBX TRUNK PORT.
(DIP SWITCH SW6 ON)
OR
AMPLIFIER
EXTERNAL
RLY
T R
OPTIONAL
-24VDC
SUPPLY
POWER
OR
HORN/SPEAKER
SELF-AMPLIFIED
OR
CONNECTIONS TO MULTI-ZONE CONTROLLERS
VP-624D
SUPPLY*
POWER
-24VDC
OTHER
SUPPLY
POWER
-
+
OR
SOURCE
MUSIC
LEVEL
LOW
*MAY BE PROVIDED
BY PAGE CONTROL.
FXS PORT
OR PBX STATION PORT.
(DIP SWITCH SW6 OFF)
VALCOM ZONE CONTROLLER
ONE-WAY OR TALKBACK
T/R INPUT
OPTIONAL
MUSIC INPUT
V-2003A, V-2006A, V-ACS, ETC.
(BATTERY FEED SWITCH ON)
Figure 3. Connections
