Rev. 5
8-6
FUSE REPLACEMENT
LOWN FUSES MUST BE REPLACED ONLY WITH FUSES OF THE SAME
TYPE AND RATING AS SPECIFIED BY THE MANUFACTURER.
HE MASTER SWITCH MUST BE IN THE
OFF
POSITION BEFORE
EPLACEMENT FUSES FOR ANY CIRCUIT IN WHICH A
FUSE OR
LARGER IS SPECIFIED MUST BE OF THE TYPE THAT ILLUMINATE WHEN BLOWN.
1. Remove the suspected blown
fuse.
2. Perform visual inspection and/or
use multi-meter to test fuse.
3. Insert new fuse with proper
rating as shown in Figure 21.
4. A recurring blown fuse indicates
excessive current draw from the
corresponding circuit of the
electrical system. See Chapter
18.
