Van's Aircraft RV-12 Maintenance Manual

Rev. 6
9-4
COMPONENTS
Quantity
Part or Assembly Name
Part Number or Reference
2
Static Source
Rivet SD-42-BSLF
1
Plastic Tee
125 X 125 X 125 TEE
1
Pitot Block
FF-1201, UHMW
1
Pitot Tube
FF-1202, AT6-058X5/16
SERVICE
▲WARNING:
A
LWAYS HAVE AN APPROPRIATE FIRE EXTINGUISHER READILY
AVAILABLE.
▲WARNING:
B
EFORE PERFORMING ANY MAINTENANCE OR REPAIRS TURN THE MASTER
SWITCH
'OFF' AND DISCONNECT THE NEGATIVE (-) BATTERY CABLE FROM THE BATTERY.
■
C
AUTION
:
R
EPLACEMENT COMPONENTS
,
WIRE
,
TERMINALS
,
AND FUSES MUST BE OF
THE SAME TYPE AND RATING AS THE ORIGINAL PARTS.
Software updates are often available online for the Dynon D-180, Skyview,
Garmin GPS, and Garmin G3X. The avionics components are not serviceable by the
consumer unless otherwise noted in the manufacturer user manuals. A manufacturer
authorized repair facility will perform diagnosis and service to the avionics components.
The Cockpit, Nav/Strobe and Landing lights have no user serviceable parts.
Check the supply voltage and circuit connections. Replace the inoperable light if
necessary.
SUPPLIES
TOOLS
EXPENDABLE
♦
Wire cutter
♦ Wire terminal crimper
♦ Needle nose pliers
♦ 3/8” combination wrench
♦ 5/64” allen wrench
♦ Razor Knife
♦ Screwdrivers
 #2 Phillips
 Small flat blade
♦ Computer with internet
♦ Unit connection cable
♦
Wire terminals
♦ Plastic Tie Wraps
REPLACEABLE
♦
See component list on page 9-2.
