2. Label, then disconnect the electrical connections attached to the component, if
applicable.
3. Disconnect the fuel line(s) attached to the component, if applicable.
4. Remove the attaching hardware and component.
INSTALLATION
1. Installation procedure is reverse of the removal procedure.
SERVICE SCHEDULE PROCEDURES
ARNING
LWAYS HAVE AN APPROPRIATE FIRE EXTINGUISHER READILY AVAILABLE
GASCOLATOR CLEANING
3/16 Standard screwdriver
¼” drive socket extension, ¼”
socket, flat blade screw bit
Safety wire pliers
Gas-5 Screen
Gas-5 O-ring gasket
Owner and SPC, LSA-RM or A&P
1. Remove the engine cowling. (12-4)
2. Move the fuel valve to the OFF position.
3. Remove the fuel quick-drain to drain the existing fuel from the gascolator bowl.
4. Remove the safety wire and screws (4) from around the gascolator bowl. (Note:
The inboard aft screw can be accessed through the hole provide in the
bottom plate of the nose gear assembly by using a ¼” drive socket
extension, a ¼” socket, and a screw bit inserted in the socket).
5. Remove the collar and the gascolator bowl. (Note: Have a container available
to catch any spillage of fuel that still remains in the gascolator and fuel
lines).
6. Use a small pointed tool to lift the edge of the filter screen and remove it for
cleaning.
INSTALLATION:
1. Installation procedure is reverse of the removal procedure.
