Rev.5
13-10
FUEL DRAIN HOSE REPLACEMENT
1/4 socket or Phillips screwdriver
Fuel interconnect and drain hoses
LSA-RM with Rotax Service certification or A&P
with Rotax Service certification
Removal
1. Cut the tie wraps attaching the drain hose to the gascolator-to-fuel-pump
hose.
2. Loosen two hose clamps on the interconnect hose and one clamp on the
drain hose and slide the clamps onto the aluminum drain tube.
3. Remove the hoses.
Installation
1. Install new hoses onto the fuel pump drain fitting and the drain tube.
2. Slide hose clamps back into position over the hoses and tighten.
3. Secure the drain hose to the gascolator-to-fuel-pump hose using tie wraps.
