Rev. 6
5-17
NOSE INNER TUBE REPLACEMENT
Owner and SPC, LSA-RM,
or A&P
Lift and support the aircraft. (1-16)
1. Remove the nose wheel and tire assembly. (5-16)
2. Deflate the inner tube.
3. Split the wheel assembly by removing the bolts (3), washers (6), and nuts (3).
4. Replace the inner tube. Orient the valve stem with the hole in the wheel and the
colored dot on the tire.
5. SLOWLY inflate the tire. Deflate it fully and re-inflate it SLOWLY a couple more
times to work out any wrinkles in the tube. Inspect for a good seat around the
wheel rim. For final inflation pressure see page 1-14.
6. Reassemble and install the wheel and tire assembly.
FLAPERON HINGE REPLACEMENT
3/8 socket
3/8 combo wrench
E PREPARED WITH ADDITIONAL PERSONEL OR TOOLS TO HANDLE THE
WEIGHT AND AWKWARDNESS OF THE OBJECT TO BE REMOVED.
1. Remove the wings. (5-13)
2. Make note of the flaperon hinge hardware configuration
3. Remove the flaperon hardware and flaperon assembly.
