Van's Aircraft RV-12 Maintenance Manual

Rev. 4
6-2
OVERVIEW
The control system enables the pilot to operate the control surfaces. Forward or
aft movements of the control stick control the pitch. The pitch control linkage is a pair of
cables, each routed around a pulley. An electronic switch wired to the pitch-trim servo,
controls the pitch-trim. Side-to-side movements of the control stick controls roll via push
rods, a bell crank, and torque tubes. Rudder pedals control yaw via cables to the
rudder.
Refer to the KAI to identify the individual parts and part #’s of the control system.
• NOTE: This maintenance manual is intended to be used in conjunction with the
RV-12 Kit Assembly Instructions (KAI) when completing maintenance or repair
processes.
COMPONENTS
Quantity
Part or Assembly Name
Part Number or Reference
1
Flap handle / Pushrod
Refer to KAI
1
Flaperon Mixer Bellcrank
F-1263A & F-1263B
2
Control stick pushrod
Refer to KAI
2
Control stick
WD-1212
2
Flaperon pushrod
Refer to KAI
1
Left flaperon torque arm
Refer to KAI
1
Right flaperon torque arm
Refer to KAI
2
Stabilator cable
F-1247A & B
2
Rudder cable
F-1239
2
Rudder pedal
WD-1206
2
Stab cable pulley
MS24566-4B
4
Locking clips
MS21256-1
1
Pitch / Trim servo
See Chapter 8
Optional Components
1
Autopilot Module
IF Dynon AP AP74V-12 or SV-AP-PANEL
and SV-KNOB-PANEL or Garmin GMC 305
1
Autopilot (Pitch) Servo
IF DYNON AP SV32 or Garmin GSA 28
1
Autopilot (Roll) Servo
IF DYNON AP SV32 or Garmin GSA 28
