Van's Aircraft RV-12 Maintenance Manual

Rev. 4
6-8
BELLCRANK BEARING REPLACEMENT
Tools
3/8, 7/16, 3/4, 11 mm socket
3/8, 7/16 combo wrench
2 1/2x3/16 bolt, washer, and
nut
Expendable
None
Replaceable
Bearing DW4K2X
Service Rating
Line
Minimum Certification
LSA-RM, or A&P
Additional
References
KAI
1. Remove the seat ramp cover and seat floor cover. (3-4)
2. Remove the pushrod-to-bellcrank hardware:
Control stick pushrod: washer and nut
Flap handle pushrod: bolt and washers (2)
Flaperon pushrod: bolt, washer and nut
3. Remove the bellcrank.
4. Use the same method instructed for extracting the DW4K2X hinge bearing on
page 5-20, Figure 16.
5. Installation procedure is reverse of the removal procedure.
RUDDER PEDAL REMOVAL
Tools
11/32, 3/8 socket
3/8 combo wrench
Needle nose pliers
#2 Phillips screwdriver
Expendable
Cotter pins
Replaceable
Rudder pedal
Service Rating
Line
Minimum Certification
LSA-RM, or A&P
Additional References
KAI
Matco user manual
1. Remove the tunnel cover. (3-4)
2. Remove the rudder pedal access covers (directly aft of the horizontal tubes of the
rudder pedals) and hardware; screws (3), washers (2) and nuts (2).
●
NOTE:
T
HE MASTER CYLINDERS CAN BE REMOVED WITHOUT DISCONNECTING THE
BRAKE LINES.
3. Label, and then remove the master cylinders (4) from the rudder pedals. (7-3)
4. Remove the rudder cable hardware from each rudder cable; cotter pin, bolt,
washers (3) and nut.
