Figure 1. Installing a Ferrite Bead on an Audio Cable
Cable Fully Looped Around Bead
Ferrite Bead
Cutout
Cutout
Audio Cable
To Connector on G.SHDSL Rear Panel
1" - 1
½
" (25-38 mm)
To Customer ’s DSL
