VariProp DF-80 - Page 13

M 14 x 2
UNC 1/2 “ -13
40 Nm
M 16 x 2
BSW 5 / 8 “ - 11
UNC 5 / 8 “ - 11
60 Nm
M 16 x 2
Für Yanmar Saildrive SD 20 und SD 31
und für alle Volvo Saildrive
60 Nm -
70 Nm
M 20 x 2,5
BSW 3 / 4 “ - 10
UNC 3 / 4 “ - 10
125 Nm
160 NmUNC 7 / 8 “ - 9
M 24 x 3
BSW 1 “ - 8
UNC 1 “ - 8
210 Nm
M 14 x 1,5
BSF 1/2 “ - 16
40 Nm
M 16 x 1,5
BSF 5 / 8 “ - 14
UNC 5 / 8 “ - 18
70 Nm
M 20 x 1,5
BSF 3 / 4 “ - 12
UNC 3 / 4 “ - 16
135 Nm
M 20 x 2
Für Yanmar Saildrive
SD 40 und SD 50
100 Nm -
120 Nm
M 24 x 2
BSF1 “ - 10
UNF 1 “ - 12
225 Nm
+
+
(see page 3, Fig. 1,part no. 4)
Fine – threadStandard – thread
Tools supplied with each VARIPROP
(pink)
»»1 small plastic bottle with Loctitelow
»»1 allen key 4 mm
»»1 allen key 3 mm
»»1 grease nipple 5mm
»»1 allen key 5 mm
»»1 allen key 5 mm
»»1 allen key 4 mm
»»1 allen key 2 mm
»»1 grease nipple 5mm
(pink)
»» 1 small plastic bottle with Loctitelow
»»1 allen key 4 mm
»»1 allen key 3 mm
»»1 open-end- / box spanner 36mm
»»1 open-end- / box spanner 8mm
»»1 allen key 4 mm
»»1 allen key 2 mm
»»1 open-end- / box spanner 32mm
»»1 open-end- / box spanner 8mm
for DF/GP-107:
for DF-80:
necessary tools for removing the prop after 3 years (page 10)
»»1 open-end- / box spanner 32mm
for DF-80:
»»1 open-end- / box spanner 13mm
»»1 allen key 2 mm
»»1 allen key 4 mm
»»1 allen key 5 mm
»»1 open-end- / box spanner 36mm
»»1 open-end- / box spanner 13mm
»»1 allen key3 mm
»»1 allen key 4 mm
»»1 allen key 6 mm
»»1 allen key 5 mm
Service tool for
Service tool for
»»1 allen key 4 mm
»»1 allen key 6 mm for socket cap screw (2)
extra for Saildrive
(Fig.1/p.4)
necessary tools for removing the prop after 1 or 2 seasons (page 9)
Service Tools DF/GP-107
(Fig.1):
Service Tools DF/GP-80
(Fig.1):
for DF/GP-80:
for DF/GP-80:
Service tool for
Service tool for
13
TORQUE SETTINGS FOR PROP-NUT
Pitch Adjustment DF/GP-80
(Fig.2/3a):
Pitch Adjustment DF/GP-107
(Fig.2/3a):
for DF/GP-107:
