ax Careline 0870 606 1248
operation/ maintenance
While making sure the dirty water tank is resting on the
base, place the rear of the tank into the base of the
cleaner, push down on the handle until it latches.
Replace top of dirty water tank by pressing it into place
(Fig 4/16).
5. Maintenance
Brush removal and replacement
NOTE: The plug must be removed from socket outlet
before cleaning or maintaining the appliance.
Remove the water tank switch off and unplug carpet
washer.
Flip the cleaner on its side to expose the nozzle base.
Lift out the floating brush bar by pressing the two
latches and pulling it gently (Fig 5/1).
Replace floating brushbar (Fig 5/2).
Fig.4/16
Fig.5/1
Fig.5/2
V-135B Infinity User Guide.qxd:V-135B User Guide 6/10/08 16:38 Page 7
