Vax Rapide Spring V-021 User Manual

Assembly
1. Line up mid-section with base unit and slot into
place (as shown).
2. Insert handle into mid-section ensuring that the
solution trigger is at the back of the machine and
the screw hole in the handle is lined up with the
scr
ew hole in the mid-section (as shown).
3. Insert and tighten screws as indicated.
4. Twist cord holder until it is facing upwards.
5. Finally insert clean water tank and machine is fully
assembled.
Preparing the Machine/Assembly
4
Fig.3/8
Fig.3/9
Fig.3/5 - Clean Water Tank
Fig.3/6
Align screw holes
Insert Screw Insert Screw
Insert Screw
Fig.3/10 Fig.3/11
V-021 User Guide.qxd 5/6/06 4:14 pm Page 5

Vax Rapide Spring V-021 Specifications

General

Brand	Vax
Model	Rapide Spring V-021
Category	Vacuum Cleaner
Language	English
