Vdwall LVP615 series Quick User Guide

地址：深圳市南山区科技园北区同方信息港 C 栋 5B 网址：www.videowall.cn
电话：
+86-755-2675 0210
传真：
+86-755-2675 0185
LVP615 系列快速使用指南
Rear panel button
1）video signal input ports 2）audio signals input and output 3）video signal outputs 4）
communication ports 5） sending card installation location
Step 1 ： sending card installation
1) Take out LVP615 processor, unscrew the sending card baffle screws and pull out the sending
card tray.
2) Install the sending card on the corresponding location of sending card tray and tighten the
screws.
3) Connect sending card +5 power cable and push the tray into the box.
4) Tighten the baffle screws. Then finish sending card installation.
