B.
Baud
Rates
*
*
During
the
initialization
process
all
USARTs
have
their
baud
factors
set.
The
actual
Baud
Rate
for
each
USART
is
determined
by
this
factor
coupled
with
an
externally
generated
timing
signal.
The
Keyboard
USART
uses
a
specially
designed
circuit
(<D13>)
to
generate
its
timing
signal.
This
circuitry
in
combination
with
the
USARTs
pre-determined
baud
factor
allows
the
keyboard
USART
to
operate
at
300
baud.
The
other
two
USARTSs
receive
their
timing
signal
from
ports
11H
and
12H
of
the
Timer
chip.
During
initialization
these
ports
are
configured
so
they
generate
a
timing
signal
which
allows
the
modem
port
to
operate
at
300
baud
and
the
serial
printer
port
to
transmit/receive
at
9600
baud.
These
rates
can
be
changed
by
reprogramming
the
timer
-and/or
changing
the
USART
baud
factor.
The
following
chart
shows
how
the
baud
rate
is
changed
by
reprogramming
the
timer.
1.
Initialize
the
USART
timer
ports.
This
includes:
Selecting
mode
3
operation,
reading/writing
in
high/low
byte
format,
configuring
counter
to
binary
counting.
T
1
(for
modem)
Send
7T6H
to
port
13.
T9
(for
printer)
Send
B6H
to
port
13.
2.
Set
Delay
Count
for
each
USART
port
by
sending
out
low
order
and
high
order
bytes.
Refer
to
Baud
Rate
Chart
(on
next
page)
to
obtain
proper
delay
count
value.
For
this
example
each
USART
will
be
set
to
generate
110
baud.
Ty
(for
modem)
Send
70H
to
port
11H.
Send
04H
to
port
11H.
Ty
(for
printer)
Send
T0H
to
port
12H.
Send
04H
to
port
12H.
See
VECTOR
4
PROGRAMMERS
GUIDE
for
more
detailed
information
on
how
baud
rates
are
selected.
II
5-16
7200-0001
