Velcon/FlexWeigh Model 5 - Load Cell Color Codes

10.0 LOAD CELL COLOR CODES
Find the Manufacturer Code from the table below:
CODE
MANUFACTURER
CODE
MANUFACTURER
2
ALLEGANY 2 NATIONAL
1
ALPHATRON 3 NCI
2
BEOWULF 1 ORMAND
2
BLH 2 REVERE
2
CARDINAL 1 SAMSON
1
ELECTROSCALE 1 SENSORTRONICS
2
EVERGREEN 1 STRAINSERT
1
FLEXWEIGH 4 TEDEA
2
HBM 2 TOLEDO
1 INTERFACE 1 TRANSDUCER
1 LEBOW
Use the Manufacturer Code found above to find the load cell color values in the table below:
MANUFACTURER CODE
FUNCTION
TB3
TERMINAL
1 2 3 4
+EXCITATION +EXC
RED GREEN RED GREEN
-EXCITATION -EXC
BLACK BLACK BLACK BLACK
+SIGNAL +SIG
GREEN WHITE WHITE RED
-SIGNAL -SIG
WHITE RED GREEN WHITE
+SENSE +SEN
YELLOW
BLUE
-SENSE -SEN
BLUE BROWN
SHIELD SHLD
