Owner’s Manual
There are 3 lights on the top of the battery next to the red button. The first is
red and the other 2 lights are green. When all 3 lights are on, they indicate a
51-100% charge. When 2 lights (one red and one green) are on, they indicate
a charge of 1 to 50%. When only the red light is on, the battery is dead. For
optimal use of the battery, it would be best to recharge it when the last green
light is on.
The battery’s charge level is also visible on the LCD Control Panel.
Red button on battery
Battery Charge Level on
LCD Control Panel
Battery Level
Assistance Level
Buttons
MODEL A2
To turn on the battery, insert the key in the battery as shown in picture A, turn
key clockwise as shown in picture B to lock the battery into the bicycle and
turn the key further clockwise as shown in picture C to activate the battery. To
turn on the system, press the ON/OFF button on the Control Panel.
Key at position A
Battery unlocked
Key at position C
Battery activated and locked
Key at position B
Battery locked
LCD Panel with the assistance
mode 0
