Owner’s Manual
MODELS R36/36V
First, make sure that the battery is lock within the frame.
To activate the R36, press -/O on the right side of the battery and -/O on
the left side of the handlebar. The LCD panel will show Assistance mode 0.
In order to use the assistance or the throttle, select the assistance level
between, 1 to 5 on the LCD panel.
If you shutdown the bicycle with the -/O on the left side of handlebar or
on the battery, the assistance Level will return to 0 when you reactivate for
security purpose.
Batterie -/O
Button on
handlebar
Analogue
console
LCD Panel with
the assistance
mode 0
Optional Digital
Control Panel
There are 4 lights on the top of the battery next to the red Button. The first
is red and will glow only if the battery is discharged; the other 3 lights are
green and indicate the charge level: 3 lights lit indicate an approximate
100% charge; 2 lights lit indicate a level of charge of about 55%; only one
light glowing indicates a charge level of approximately 25%.
The battery’s charge level is visible on the Control Panel or on the battery.
36V
Battery Level
Battery Level
Assistance Level
Buttons
Battery Level
Analogue console
Optional Digital
Control Panel
