VelectriX REENTION Mini Eel - Battery Operation and Indicators; Power Connection and Lock Mechanism; Battery Charge Level Indicators

Main power connection/discharge point housed
in battery top
Key lock/barrel housed in bike frame
To check the state of charge, press the button
on the top. The colour of the LED indicates the
level of battery charge:
o Blue: More than 90% charge
o Green: 40 – 90% charge
o Red: 20 – 40% charge
o Flashing Red: Less than 20% charge
If access is required to the top of the battery,
remove the 4 screws and pull the battery top away
from the main battery body to expose the wiring
for the charger port, charge indicator circuit board
and the main 30 Amp fuse
