VELFAC 200 - VELFAC 207 Sideguided window; Friction adjustment; Cleaning and care

15
1. 2.
3.
4.
A
B
C
5.
The window opens by turning the handle to a vertical position and
pushing the sash outwards until the safety restrictor engages at an
opening of 5-10cm.
Cleaning. The external side of the window can be cleaned from inside
the building by reversing the sash. Open the window until the safety
restrictor is activated. Pull back the window slightly and detach the
restrictor (1). The restrictor has a lock function (the red plate). When
locked, the window cannot be reversed for cleaning.
Pushthewindowoutwards-DONOTLEANOUTwhiledoingso.
When pushed outwards, the top of the sash can be pulled gently
downwards toward the bottom of the window. The sash is fully
reversed when the catches engage to keep it in the cleaning position
(2+3).Makesurethesashisxedincleaningpositionbeforestarting
to clean.
When the sash has been cleaned, the catches can be disengaged
(2+3): Pull back the window slightly and detach catch 1, move the
sashslightlyupwardsanddetachcatch2.Nowthebottomofthe
sash can be guided back towards the top. The safety restrictor will
automaticallyre-engagewhenthesashisclosed.Neverleavethe
window unattended while the restrictor is disengaged!
IMPORTANT. The guide rails of the friction arm should be kept free
from dirt (4).Theyshouldbesprayedwithteon-basedlubricating
oilorasimilarproductonceayear,asaminiumum(Neverall-round
lubricating oil!).
VELFAC 228 Tophung fully reversible window
Locked in ventilation position. Lock the
restrictor by pushing the red plate until a
click is heard.
NB:Donotlocktherestrictor,whenyou
want to reverse the window for cleaning.
Unlock
Lock
