Connection
24. CONNECTION
Connect a battery to the ACCU + and - connection. One of
the battery holders from our range can be used such as:
• Type BH9V for 1 9V cell.
• Type BH322B for 2 AA cells (penlight).
• Type BH341B for 4 AA cells.
• Type BH363B for 6 AA cells.
• Type BH383B for 8 AA cells.
Type BH9V
Type BH322B
-
+
-
+
DC adapter of 15V/800mA
(ex. type PS1508)
