VASDAC
V. 02 – 04/04/2013 4 ©Velleman nv
Only use the device for its intended purpose. Using the device in an
unauthorised way will void the warranty.
Damage caused by disregard of certain guidelines in this manual is not
covered by the warranty and the dealer will not accept responsibility for
any ensuing defects or problems.
Keep this manual for future reference.
4. Features
This audio converter converts a digital TOSLINK or S/PDIF signal to an
analogue stereo signal.
The converter can be used if an amplifier does not have any digital inputs or
if you want to connect more digital sources to one amplifier.
input:
o digital coaxial audio: S/PDIF
o optical audio: TOSLINK
output:
o analogue stereo audio: coaxial stereo
5. Overview
Refer to the illustrations on page 2 of this manual.
1
COAXIAL IN: RCA coaxial cable
input
6
DC power supply connector
2
OPTICAL IN: TOSLINK cable
input
7
coaxial/optical selector switch
3
power indicator
8
TOSLINK input device, e.g. DVD
player
4
AUDIO OUT R: RCA audio output
9
coaxial input device, e.g. set top
box
5
AUDIO OUT L: RCA audio output
10
amplifier and speakers
6. Installation
Refer to the illustrations on page 2 of this manual.
Caution: Before installation, switch off all audio/video devices and unplug
the power adapter of the converter. Switch on all devices after all the
connections are made.
1. Slide the selector switch [7] in the desired position:
o COAXIAL: if you use a S/PDIF coaxial cable (not incl.)
o OPTICAL: if you use a TOSLINK cable (not incl.).
Notes: TOSLINK fibre cable is fragile, handle with care and do not bend. Do
not touch the optical fibre ends of the cable while you make the
connections.
