6. PARTS LIST / LISTA DE PARTES / LA LISTE DU PIÉCES
No/Nu/No Qty/Cant/Qté Description/Descripción/Description
NO. DESCRIPTION SIZE QTY NO. DESCRIPTION SIZE QTY
1 MAIN FRAME 1 42 PROTECTION COVER 1
2 FRONT STABILIZER 1 43 ADORNMENT COVER (L&R) 2
3 REAR STABILIZER 1 44 SCREW ST4.2X16 2
4 FRONT POST 1 45 BOLT M6X12 2
5 HANDLEBAR 1 46 BRAKE BLOCK 1
6 SEAT POST 1 47 BRAKE BRACKET 1
7 CARRIAGE BOLT M8X55 4 48 WASHER Φ5 2
8 WASHER Φ8 4 49 BOLT M5X10 1
9 ACORN NUT M8 4 50 BRAKE PAD 1
10 END CAP 4 51 BOLT M4X6 1
11 ADJUSTABLE FOOT M10 4 52 ROUND NUT M12 1
12 HEX BOLT M6X45 2 53 NUT M12 1
13 MOVING WHEEL 2 54 SPRING 1
14 WASHER Φ6 6 55 BUSHING 1
15 NYLON NUT M6 2 56 NYLON BUSHING 1
16 HOUSING 2 57 BREAK BAR Φ12X250 1
17 BEARING 6004 4 58 BREAK COVER 1
18 BOLT M6X12 4 59 BOLT M5X6 2
19 FLYWHEEL 1 60 BRAKE(TENSION) KNOB M10 1
20 BOLT M6X35 4 61 L-KNOB M10 4
21 BOLT M6X20 2 62 WASHER Φ38XΦ11X4 2
22 NUT M6 5 63 ADJUSTING NUT 2
23 AXIS 1 64 LOCK BLOCKS 2
24 PLASTIC WASHER 1 65 BUSHING 2
25 LITTLE BELT WHEEL 1 66 END CAP 30×70 2
26 BOLT M6X15 4 67 SEAT BRACKET 1
27 FREE WHEEL 1 68 SADDLE 1
28 BOLT M6X40 1 69 SHAFT 1
29 PEDAL(L&R) 2 70 BEARING 6003 2
30 END CAP FOR CRANK 2 71 WASHER Φ10 2
31 FLANGED DOME NUT M10X1.25 2 72 NUT 1
32 CRANK（L&R） 2 73 SCREW M4X10 1
33 SCREW ST4.2X10 7 74 SENSOR CABLE 1
34 SCREW ST4.2X16 3 75 MONITOR HOLDER 1
35 CHAIN COVER 1 76
SCREW
M4×20 1
36 BELT 1 77 MONITOR 1
37 FLYWHEEL SHAFT 1 78 MONITOR CABLE 1
38
FIXING TUBE Φ25X1.5X8 1 79 OUTLET CABLE 1
39 INNER CHAIN COVER 1 80 MAGNET 1
40 SCREW ST4.2X10 2 81 SENSOR HOLDER 1
41 CIRCLIP 1
