TECHNICAL MANUAL
MODEL
Data concern medium water
temperature of 9,5°C
VCE10 VCE20 VCE30 VCE40 VCE50 VCE60 VCE70 VCE80 VCE90 VCE100 VCE110 VCE120
MODEL
WORK LIMITS
Maximum input water temperature 80 °C
Minimum input water temperature + 4 °C
Maximum working pressure 8 bar
Maximum input air temperature 32 °C
Minimum input air temperature + 4 °C
Water flow and pressure drop limits, 3R coil
Maximum water pressure drop
Minimum water flow
Minimum water pressure drop
Maximum water flow
l/h 125 100 100 100 100 100 75 125 125 200 275 275
kPa 0,6 0,4 0,5 0,5 0,6 0,6 0,5 0,5 0,5 0,6 0,5 0,6
l/h 1.275 1.200 1.125 1.150 1.025 1.000 850 1.400 1.400 2.075 2.900 2.850
kPa 58,6 59,5 59,6 61,2 59,2 59,0 62,0 59,1 60,1 60,6 60,6 60,4
Water flow and pressure drop limits, 1R coil
l/h 150 150 125 125 125 125 125 100 100 125 125 125
kPa 0,6 0,6 0,5 0,5 0,6 0,5 0,6 0,6 0,5 0,5 0,5 0,5
l/h 1.550 1.500 1.400 1.375 1.275 1.350 1.225 1.100 1.100 1.375 1.325 1.325
kPa 60,7 59,3 60,3 61,0 61,0 60,4 59,5 59,0 60,1 59,6 59,7 58,8
3 way valves
Using of 2 or 3 way valves is compulsory when the unit is used for cooling to avoid condensate in the external structure (bearing structure and cabinet). As alternative
install a regulating system to stop coil water entering when the fan is off.
Maximal fan static pressure
When the unit is connected with ducts fan air flow is reduced due to the ducting pressure drops.
With very high pressure drops fancoil air flow becomes too low and electric motor which is connected to the fan can be damaged. For this reason we recomand static
pressures lower than the maximal limit static pressures indicated in the schedule.
NOTE: when the fancoil is operating with the maximal operating indicated static pressure value, air flow is half in comparison with the unit without ducts at the same
working speed.
Definitively the static pressure limit value corresponds to the back pressure ables to halve fancoil air flow (as a consequence the fancoil unit performances like heating
& cooling capacity, will be reduced of about 50%).
2 pipe system
Pa 1 9 12 7 9 19
min
12 15 41
min
33
min
44 37 47
Pa 2 11
min
15
min
10
min
11
min
22 16
min
19 51
med
41 49
min
47
min
58
min
Pa 3 15 19
med
15
med
17
med
28
med
22 26
min
55
max
45
med
62
med
68
med
74
Pa 4 18
med
25
max
19
max
22 32
max
28
med
34
med
60 49 68 76 80
med
Pa 5 25
max
32 25 27
max
40 36
max
44
max
65 53
max
75
max
84
max
84
max
Pa632403237 4945 54706084
Pa 1 8 10 6 8 14
min
10 11 30
min
27
min
43 37 47
Pa 2 9
min
12
min
8
min
9
min
17 13
min
15 38
med
33 48
min
47
min
58
min
Pa 3 11 15
med
13
med
14
med
21
med
18 20
min
42
max
37
med
61
med
67
med
73
Pa 4 15
med
19
max
15
max
17 25
max
22
med
28
med
50 40 67 75 79
med
Pa 5 19
max
25 19 22
max
32 28
max
36
max
55 44
max
74
max
83
max
82
max
Pa625322430 3835 44605182
4 pipe system
Maximum water pressure drop
Minimum water flow
Minimum water pressure drop
Maximum water flow
VCE10 VCE20 VCE30 VCE40 VCE50 VCE60 VCE70 VCE80 VCE90 VCE100 VCE110 VCE120
MODELLO
Data concern medium water
temperature of 65°C
VCE10 VCE20 VCE30 VCE40 VCE50 VCE60 VCE70 VCE80 VCE90 VCE100 VCE110 VCE120
Data indicated as min, med, max, concern the 3 standard speeds set at the factory. upon customer request other 3 speeds among the 6 speeds
available can be connected.
range
7
