TECHNICAL MANUAL
FAN-COIL GENERAL DIMENTIONS FOR 2 PIPE SYSTEM (VCE 70-120)
FAN-COIL GENERAL DIMENTIONS FOR 4 PIPE SYSTEM (VCE70 - 120)
MODEL VCE70 VCE80 VCE90 VCE100 VCE110 VCE120
Fans number n° 2 2 2 3 3 3
Coils number n° 1 1 1 1 1 1
Rows number n° 3 3 3 3 3 3
Finned pack length mm 890 1.090 1.090 1.225 1.525 1.525
Number of pipes for row n° 12 12 12 12 12 12
Fin spacing mm 2,5 2,1 2,1 2,1 2,5 2,1
Number of feeding circuits n° 3 6 6 6 8 8
Shape mm x mm 25 x 22 25 x 22 25 x 22 25 x 22 25 x 22 25 x 22
Finned pack depth mm 66 66 66 66 66 66
Frontal surface m2 0,267 0,327 0,327 0,368 0,458 0,458
Fins total surface m2 15,088 18,479 18,479 20,767 21,996 25,853
Water content litri 2,42 2,93 2,93 3,28 4,04 4,04
Hydraulic connections (Ø female gas) Ø 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Lenght with cabinet L (mm) 1.260 1.460 1.460 1.660 1.960 1.960
Lenght without cabinet M (mm) 1.020 1.220 1.220 1.380 1.680 1.680
Net weight kg 30 35 36 46 55 57
Fans number n° 2 2 2 3 3 3
Coils number n° 2 2 2 2 2 2
Rows number n° 3 3 3 3 3 3
Finned pack length mm 890 1.090 1.090 1.225 1.525 1.525
Number of pipes for row n° 12 12 12 12 12 12
Fin spacing mm 2,1 2,5 2,1 2,1 2,5 2,1
Number of feeding circuits n° 3 6 6 6 8 8
Shape mm x mm 25 x 22 25 x 22 25 x 22 25 x 22 25 x 22 25 x 22
Finned pack depth mm 66 66 66 66 66 66
Frontal surface m2 0,267 0,327 0,327 0,368 0,458 0,458
Fins total surface m2 15,088 18,479 18,479 20,767 21,996 25,853
Water content litri 2,42 2,93 2,93 3,28 4,04 4,04
Hydraulic connections (Ø female gas) Ø 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Rows number n° 1 1 1 1 1 1
Finned pack length mm 880 1.080 1.080 1.225 1.525 1.525
Number of pipes for row n° 12 12 12 12 12 12
Fin spacing mm 2,1 2,5 2,1 2,1 2,5 2,1
Number of feeding circuits n° 1 1 1 2 3 3
Shape mm x mm 25 x 25 25 x 25 25 x 25 25 x 25 25 x 25 25 x 25
Finned pack depth mm 25 25 25 25 25 25
Frontal surface m2 0,176 0,216 0,216 0,368 0,458 0,458
Fins total surface m2 3,877 9,515 9,515 8,095 8,558 10,077
Water content litri 0,53 1,29 1,29 1,09 1,35 1,35
Hydraulic connections (Ø female gas) Ø 1/2" 1/2" 1/2" 1/2" 1/2" 1/2"
Lenght with cabinet L (mm) 1.260 1.460 1.460 1.660 1.960 1.960
Lenght without cabinet M (mm) 1.020 1.220 1.220 1.380 1.680 1.680
Net weight kg 32 38 39 49 58 60
MODEL VCE70 VCE80 VCE90 VCE100 VCE110 VCE120
Coil used for both
cooling and heating
General features
Cooling coil
Heating coil
General features
range
