Model
VENTING HP 18RA HP24RB
Power supply Ph-V-Hz 220-240V~ 50Hz, 1Ph 220-240V~ 50Hz, 1Ph
Cooling
Capacity Btu/h 18000 24000
Input W 1656 2190
Rated current A 7.2 10.11
EER W/W 3.2 3.20
Heating
Capacity Btu/h 19100 24900
Input W 1557 2.210
Rated current A 6.77 9.89
COP W/W 3.61 3.60
Indoor air flow (Hi/Mi/Lo) m3/h 850 950
Indoor noise level (Hi/Mi/Lo) dB(A) 38 42
Indoor unit
Dimension(W*D*H) mm 1080X310X215 1090X315X220
Packing (W*D*H) mm - -
Net/Gross weight Kg 15/17 15/17
Outdoor noise level dB(A) 54 55
Outdoor unit
Dimension(W*D*H) mm 800X590X300 800X690X300
Packing (W*D*H) mm - -
Net/Gross weight Kg 44/48 45/49
Refrigerant type g R410/1250g R410/1630g
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ15.88(3/8"/5/8")
Max. refrigerant pipe length m 10 15
Connection wiring 2.5 2.5
Indoor(cooling/ heating) ℃
Outdoor(cooling/heating) ℃
Operation
temperature
17～32 17～32
18～43/-7～24 18～43/-7～24
