Ventrac KC180 - Page 23

PARTS
Illustrated Parts - 23
Use only original Ventrac
replacement parts.
REF. PART NO. DESCRIPTION QTY.
1 .........44.0195 ....................SHIELD, RUBBER ........................................................ 3
2 .........64.0958 ....................BAR, RUBBER CLAMP .................................................... 2
3 .........62.0911 ....................FRAME, MAIN & HITCH .................................................... 1
4 .........60.0818 ....................SHIELD, DRIVE BELT GEARBOX ........................................... 1
5 .........64.0957 ....................STAND, SUPPORT ........................................................ 1
6 .........03.0009 ....................PIN, SAFETY SNAP 1/4 X 1-3/8 .............................................. 1
7 .........99.SF0405-1 ................BOLT, SMF 1/4-20 X 5/8 .................................................... 9
8 .........99.A04 .....................LOCKNUT, STOVER 1/4-20 USS ............................................ 9
9 .........99.SF0404 .................BOLT, SRF 1/4-20 X 1/2 .................................................... 2
10 ........99.SF04 ...................NUT, SRF 1/4-20 USS ...................................................... 8
11 .........99.SF05 ...................NUT, SRF 5/16-18 USS ..................................................... 2
12 ........60.0816 ....................SHIELD, MAIN DRIVE COVER .............................................. 1
13 ........60.0817 ....................SHIELD, BOTTOM FINAL BELTS ............................................ 1
14 ........64.0956 ....................COVER, ROTOR OPENING ................................................ 1
15 ........00.0192 ....................DECAL, V-DECAL DIE CUT BLUE ........................................... 1
16 ........00.0101 ....................DECAL, HAZARD-MOVING PART ........................................... 1
17 ........00.0123 ....................DECAL, KEEP HANDS & FEET CLEAR ....................................... 1
18 ........00.0102 ....................DECAL, DANGER-PINCHING HAZARD ...................................... 1
19 ........00.0189 ....................DECAL, VENTRAC ORBITAL ............................................... 1
20 ........90.0412 ....................BOLT, 1/4-20 USS X 1 1/2 ................................................... 1
21 ........99.SF0404-1 ................BOLT, SMF 1/4-20 X 1/2 .................................................... 2
22 ........00.0100 ....................DECAL, MADE IN USA ..................................................... 1
23 ........00.0217 ....................DECAL, WARNING READ OWNERS MAN .................................... 1
Main Frame & Shields
