PARTS
Illustrated Parts - 25
Use only original Ventrac
replacement parts.
REF. PART NO. DESCRIPTION QTY.
1 .........81.B053 ....................BELT, B53 ............................................................... 1
2 .........83.H20 ....................BUSHING, 1 1/4” H ........................................................ 1
3 .........83.BK80H ..................PULLEY, 8” H-BUSH ....................................................... 1
4 .........90.0808 ....................BOLT, 1/2-13 USS X 1 ...................................................... 4
5 .........96.08 ......................WASHER, LOCK 1/2 ....................................................... 8
6 .........87.0190 ....................GEARBOX, SUPERIOR KC180 .............................................. 1
7 .........83.3TB38 ..................PULLEY, 3-GROOVE X 3.8” DIA ............................................. 1
8 .........85.K0410 ...................KEY, 1/4 X 1 1/4 ........................................................... 1
9 .........83.P120 ....................BUSHING, 1 1/4” P1 ....................................................... 1
10 ........81.BX028 ..................BELT, BX28 .............................................................. 3
11 .........83.P123 ....................BUSHING, 1 7/16” P1 ...................................................... 1
12 ........83.3TB58 ..................PULLEY, 3-GROOVE X 5.8” DIA ............................................. 1
13 ........55.PB22023 ................BEARING, PILLOW BLOCK 1 7/16 ........................................... 2
14 ........42.0445 ....................ADJUSTER, BELT TIGHTENER BKT ......................................... 2
15 ........92.08 ......................NUT, 1/2-13 USS .......................................................... 8
16 ........95.08 ......................WASHER, FLAT 1/2 SAE ................................................... 8
17 ........85.K0610 ...................KEY, 3/8 X 1 1/4 ........................................................... 1
18 ........99.K0090 ...................BOLT, SHCS 5/8-18 SAE X 1-1/2 (Serial # 1001-1230) ........................... 18
19 ........80.0318 ....................SHAFT, CUTTER ROTOR (Serial # 1001-1230) ................................. 1
20 ........79.0056 ....................TOOTH, STRAIGHT C-BORED KC180 (Serial # 1001-1230) ....................... 3
21 ........79.0055 ....................TOOTH, STRAIGHT TAPPED KC180 (Serial # 1001-1230) ........................ 3
22 ........79.0054 ....................TOOTH, LEFT C-BORED KC180 (Serial # 1001-1230) ............................ 6
23 ........79.0053 ....................TOOTH, RIGHT TAPPED KC180 (Serial # 1001-1230) ............................ 6
24 ........85.K030410 .................KEY, 3/16 X 1/4 X 1-1/4 ..................................................... 1
25 ........80.0376 ....................ROTOR, STUMPGRINDER KC180 (Serial # 1231-) .............................. 1
26 ........79.0085 ....................TOOTH, DEEP DISH W/NUT (Serial # 1231-) .................................. 16
26 ........79.0089 ....................TOOTH, STD DISH W/NUT (Optional Tooth) ................................... 16
27 ........79.0087 ....................MOUNT, TOOTH STRAIGHT (Serial # 1231-) ................................... 8
28 ........79.0086 ....................MOUNT, TOOTH ANGLED (Serial # 1231-) ..................................... 8
29 ........99.K0114 ...................BOLT, CUTTING TOOTH MOUNT (Serial # 1231-) .............................. 16
40 ........99.A06N ...................LOCKNUT, NYLON 3/8-16 .................................................. 1
41 ........64.1641 ....................SPACER, CUTTING TOOTH ................................................ 1
45 ........29.0093 ....................PIPE, BREATHER PLUG 1/4 ................................................ 1
46 ........29.B0204G .................PIPE, BUSHING 1/8 X 1/4 GALV ............................................. 1
47 ........55.0078 ....................BEARING, CUP 2.717 ...................................................... 4
48 ........55.0077 ....................BEARING, CONE 1.375 .................................................... 4
49 ........04.0027 ....................RETAINING RING, EXT 1.375 SHFT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
50 ........89.0082 ....................SEAL, 1.375-2.00-313 ...................................................... 2
51 ........89.0083 ....................SEAL, END CAP 2.00-312 .................................................. 1
Drive & Pulleys
