PARTS
Illustrated Parts - 27
Use only original Ventrac
replacement parts.
REF. PART NO. DESCRIPTION QTY.
1 .........64.0970 ....................HANDLE, MIRROR BKT LOCK .............................................. 2
2 .........64.0969 ....................BRACKET, MIRROR MOUNT LEFT .......................................... 1
3 .........64.0968 ....................BRACKET, MIRROR MOUNT RIGHT ......................................... 1
4 .........62.0916 ....................FRAME, MIRROR ARM .................................................... 2
5 .........00.0189 ....................DECAL, VENTRAC ORBITAL ............................................... 1
6 .........99.A06 .....................LOCKNUT, STOVER 3/8-16 USS ............................................ 2
8 .........95.06 ......................WASHER, FLAT 3/8 SAE ................................................... 4
9 .........90.0610 ....................BOLT, 3/8-16 USS X 1 1/4 ................................................... 2
10 ........99.A04 .....................LOCKNUT, STOVER 1/4-20 USS ............................................ 4
11 .........95.04 ......................WASHER, FLAT 1/4 SAE ................................................... 8
12 ........90.0412 ....................BOLT, 1/4-20 USS X 1 1/2 ................................................... 4
13 ........99.K0062 ...................MACHINE SCREW, #10-32 X 1/2 ............................................. 4
14 ........05.0084 ....................BUMPER, CYLINDRICAL RUBBER .......................................... 4
15 ........99.A1032N .................LOCKNUT, NYLON 10-32 STAINLESS ........................................ 4
16 ........60.0821 ....................FRAME, MIRROR MOUNT ................................................. 1
17 ........47.0199 ....................MIRROR, ACRYLIC LENS 18” X 12” .......................................... 1
18 ........90.0508 ....................BOLT, 5/16-18 USS X 1 .....................................................6*
19** .......95.05 ......................WASHER, FLAT 5/16 SAE ..................................................6*
20** .......99.SF05 ...................NUT, SRF 5/16-18 USS .....................................................6*
*HT4000 uses 6) nuts and bolts. KT4100, KT4200, & KN4500 use 4) nuts and bolts.
**The nuts and some of the washers are reused from the power unit.
