E - 1E - 8 E - 9
CUSTOMIZING THE FUNCTION SETTINGS
Specifications and external appearance are subject to change without notice.
SAFETY PRECAUTIONS
The lightning flash with an arrowhead
symbol, within the equilateral triangle, is
intended to alert the user to the presence
of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufficient magnitude to cause an electric shock.
The exclamation point within the
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in this owner’s manual.
* SEE BOTTOM OF UNIT FOR GRAPHIC SYMBOLS *
This product
contains a low
power laser device.
On Placement
• Do not use the unit in places that are extremely hot, cold, dusty, or humid.
• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it with a cloth, or by
placing it on carpeting.
On Safety
• When connecting or disconnecting the AC power adapter, grip the plug and not the cord itself. Pulling the cord
may damage it and create a hazard.
• When you are not going to use the unit for a long period of time, disconnect the AC power adapter.
On Condensation
• When left in a heated room where it is warm and damp, water droplets or condensation may form inside the unit.
When there is condensation inside the unit, the unit may not function normally. Let the unit stand for 1 to 2 hours
before turning the power on, or gradually heat the room and allow the unit to dry before use.
Rating Plate Location
• The rating plate is located on the bottom of the unit.
FCC Statements
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an AC power outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
DO NOT PLACE OBJECTS FILLED WITH LIQUIDS ON OR
NEAR THIS UNIT.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
CAUTION: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE.
THIS CLASS B DIGITAL APPARATUS COMPLIES WITH
CANADIAN ICES-003.
WARNING: Should any trouble occur, disconnect the AC power adapter and refer servicing to a qualified
technician.
Notes on Copyright
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, or rent copyrighted material
without permission.
Apparatus Claims of U.S. Patent Nos. 6,836,549; 6,381,747; 7,050,698; 6,516,132 and 5,583,936 licensed for
limited viewing uses only.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended
for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering
or disassembly is prohibited.
CAUTION
INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
Printed in China
811-628191W011
Cleaning the Disc
A defective or soiled disc inserted into the unit can cause sound to drop out during playback.
Handle the disc by holding its inner and outer edges.
• Do NOT touch the surface of the unlabeled side of the disc.
• Do NOT stick paper or tape on the surface.
• Do NOT expose the disc to direct sunlight or excessive heat.
• Clean the disc before playback. Wipe the disc from the center outward with a cleaning cloth.
• NEVER use solvents such as benzine or alcohol to clean the disc.
• Do NOT use irregular shaped discs (example: heart shaped, octagonal, etc.). They may cause malfunctions.
Cleaning the Unit
• Be sure to turn the unit off and disconnect the AC power adapter before maintaining the unit.
• Wipe the unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth that has been dipped
in a weak soap-and-water solution and wrung out thoroughly, then wipe with a dry cloth.
• Never use alcohol, benzine, thinner, cleaning fluid or other chemicals. Do NOT use compressed air to remove dust.
Important Note
• Before transporting the unit, remove the disc from the disc compartment.
MAINTENANCE
TROUBLESHOOTING GUIDE
SYMPTOM CAUSE (AND REMEDY)
• Ensure the AC power adapter is connected.
• The unit is not turned on.
• Make sure the infrared remote sensor is not blocked.
• Make sure the plastic sheet has been removed from the remote control.
• Point the remote directly at the infrared remote sensor on the unit.
• Replace the battery in the remote control with a new one.
• Use remote control with GREEN keys with the unit which has GREEN buttons.
Use remote control with BLUE keys with the unit which has BLUE buttons.
• Make sure that ON mode is selected.
• The system is in pause mode. Press the PLAY button to return to normal play mode.
• The unit is in fast-forward or fast-reverse mode. Press the PLAY button to return to normal
play mode.
• Make sure the AUDIO/VIDEO output connections are correct.
• The DTS DVD cannot be decoded to have speaker output.
• The unit is too hot; shut off the unit for 30 minutes to cool it down.
• The region number of the disc doesn't match the region number of this unit.
• Clean the disc.
• The disc is scratched.
• Adjust the LCD's brightness and contrast using the VIDEO MODE button on the remote
control.
• The plugs and jacks are dirty. Wipe them with a cloth slightly moistened with alcohol.
• Clean the disc.
• There is no disc inside (“No Disc” appears on the screen).
• Insert the disc correctly with the playback side facing down.
• Clean the disc.
• A non-NTSC disc has been inserted. The unit and disc region number are incompatible.
• Condensation may have formed inside the unit due to a sudden change in temperature.
Wait about an hour for it to clear and try again.
No power.
The remote
control does not
function.
No sound or only
a very low-level
sound is heard.
No picture.
The picture is not
clear.
Severe hum or
noise is heard.
The disc does not
play.
DVD PROGRAMMABLE MEMORY
VIEWING JPG FILES
Need More Help?
DO NOT RETURN THIS PRODUCT TO THE STORE
Please visit online help at
http://www.venturer.com
DUAL SCREEN PORTABLE DVD PLAYER
OWNER’S MANUAL
You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat, A-B repeat)
Repeating a Chapter
1. While the DVD is playing, press the REPEAT DISC button until the “
Chapter
” indicator displays on the screen.
The current chapter is played repeatedly.
Repeating a Title
2. While the DVD is playing, press the REPEAT DISC button until the “
Title
” indicator displays on the screen.
The current title is played repeatedly.
To Resume Normal Playback
3. While the DVD is playing, press the REPEAT DISC button until the “
Repeat Off
” indicator displays on the screen.
You can play a single track or the whole disc repeatedly.
Repeating a Single Track
1. While the CD is playing, press the REPEAT DISC button until the “
Repeat One
” indicator displays on the screen.
The current track is played repeatedly.
Repeating the Whole Disc
2. While the CD is playing, press the REPEAT DISC button until the “
Repeat All
” indicator displays on the screen.
The whole disc is played repeatedly.
To Resume Normal Playback
3. While the CD is playing, press the REPEAT DISC button until the “
Off
” indicator displays on the screen.
Repeating a Specific Section
You can play a specific section repeatedly.
1. While the disc is playing, press the REPEAT A-B button at the beginning of the section (“
A
” is displayed)
you want to play repeatedly.
2. Press the REPEAT A-B button again at the end of the section (“
AB
” is displayed).
3. The Unit will immediately begin replaying your selection.
To Resume Normal Playback
4. While the disc is playing, press the REPEAT A-B button until the “
AB OFF
” indicator displays on the screen.
Notes:
• Some discs may not permit A-B repeat operation.
• You cannot set the A-B repeat function for a segment that includes multiple camera angles.
• You can specify a segment only within the current title or track.
• There may be a slight difference between point A and the location where playback actually resumes depending
on the disc.
Locating a Specific Chapter
If you know the chapter number for the chapter that you want to play, you can locate it by directly selecting that
number.
1. Press the GOTO button.
2. Press the corresponding number buttons (2 digits) for the chapter you want. (For example: 02, 08, 10 or 15.)
(If you press only 1 numeric button, press the ENTER button to confirm.)
3. Playback starts from the selected chapter.
Notes:
• If the chapter number entered is not permitted by the DVD, "
Input invalid
" will display. You should press the
GOTO button again and re-enter correct number.
• Some discs may not respond to this process.
• This method of locating a chapter is available only on a DVD that contains chapter numbers.
Locating a Specific Title
If a DVD contains title numbers, you can locate a specific title by directly selecting its title number.
1. Press the GOTO button.
2. Press the / button to highlight title number, press the corresponding number buttons (2 digits) for the title
you want. (For example: 02, 08, 10 or 15.) (If you press only 1 numeric button, press the ENTER button to confirm.)
3. Playback starts from the selected title.
Notes:
• If the title number entered is not permitted by the DVD, "
Input invalid
" will display. You should repeat steps
1 and 2 to re-enter correct numbers.
• Some discs may not respond to this process.
• This method of locating a title is available only on a DVD that contains title numbers.
Locating a Specific Time
You can move to a specific location by entering its corresponding time (hours, minutes, seconds).
1. Press the GOTO button two times.
2. Press the corresponding number buttons (5 digits: X:XX:XX, for example: 0 30 05, 1 08 23, 1 22 56.) for the
setting point you want.
3. Playback starts from the selected section.
Notes:
• If the time entered is not permitted by the DVD, "
Input invalid
" will display. You should re-enter correct time.
• Some discs may not respond to this process.
• Some scenes may not be located as precisely as you specified.
• This method for accessing specific locations is available only within the current title of the DVD.
LOCATING A DESIRED SECTION
3. Press the PLAY button to start memory playback. (“
Program
” appears on the screen.)
4. To resume normal playback from memory playback
1). Press the MEMORY button to display the memory menu.
2). Use the Cursor buttons ( , , , ) to move the highlighted bar to “Stop”. Press the ENTER button to confirm
“Stop”.
3). Press the ENTER button to confirm “Exit”. It will return to normal playback. (“
Program
” disappear from the
screen.)
Notes:
• If the title or chapter number entered is not permitted by the DVD, it will disappear. You should re-enter correct
number.
• You should input items one by one following the 1, 2, 3 ... sequence.
• If the DVD contains only one title, you can only arrange order for chapters.
• Some discs may not permit memory playback operation.
• If you select repeat during memory playback, the DVD player repeats the current memory playback.
• If you press the MEMORY button while the display appears on the TV screen, the display disappears.
• The programmed selections will be cleared when you press the STOP button two times, open the disc tray
or turn off the DVD player.
This unit can play JPG files recorded on a CD-R or CD-ROM disc (CD-RW is not recommended).
Viewing JPG Files
1. Press and hold the open knob to open the disc door.
2. Hold a JPG file disc by its edges and gently push it onto
the spindle with the label side facing up until you hear a
“click”.
3. Close the disc door. The JPG files on the disc will be
displayed one by one automatically.
4. Press the MENU or
STOP button to display a folder list.
Press the / button to highlight a JPG file to play. Press
the PLAY button to start playback.
Notes:
• You can press the PAUSE button to freeze the picture. Press the PLAY button to resume picture slide
show.
• You can press the STOP button to quit playback.
• You can press the PREV or NEXT button to change the picture.
• You can press the ANGLE button to rotate direction of the picture by 90
o
.
• Some discs may not permit this operation.
00:00 00:00
001/035
\
DSCN0281
DSCN0282
DSCN0283
DSCN0284
DSCN0285
DSCN0286
Language Setup
1. Press the SETUP button in stop mode.
2. Press the button to select Language Setup Page.
3. Press the / button to select the option (OSD Language,
Audio, Subtitle or Disc Menu), then press the button.
4. Press the / button to select your preferred language,
then press the ENTER button to confirm.
5. Repeat steps 3 and 4 to adjust other options. Press the
button to return to the previous menu.
6. Press the SETUP or RETURN button to exit the menu.
Notes:
• Some DVDs may not play in the audio language selected. A prior language may be programmed on the disc.
• Some DVDs may be set to display subtitles in a language other than the one you selected. A prior subtitle
language may be programmed on the disc.
• Some DVDs allow you to change subtitle selections only via the disc menu. If this is the case, press the MENU
button and choose the appropriate subtitle language from the selection on the disc menu.
• Some DVDs may not include your pre-selected language. In this case, the DVD player automatically displays
disc menus consistent with the disc's initial language setting.
Go To Language Setup Page
- - Language Setup Page - -
System
Language
Video
OSD Language
Audio
Subtitle
Disc Menu
Eng
Eng
Off
Eng
Video Setup
1. Press the SETUP button in stop mode.
2. Press the / button to select Video Setup Page.
3. Press the / button to select the option (Brightness or
Contrast), then press the button.
4. Press the / button to adjust the setting, then press the
ENTER button to confirm.
5. Repeat steps 3 and 4 to adjust other options. Press the
button to return to the previous menu.
6. Press the SETUP or RETURN button to exit the menu.
Brightness
Contrast
Go To Video Setup Page
- - Video Setup Page - -
Language
00
00
System
Video
Playing Titles/Chapters in a Favourite Order
You can combine your favourite titles/chapters and play them in the order you determine.
1. Press the MEMORY button while a DVD is playing. The following display appears.
Tv Display
Default
Wide
No
Go To System Page
- - System Page - -
System
Language
Video
System Setup
1. Press the SETUP button in stop mode.
2. Press the / button to select System Page.
3. Press the / button to select the option (TV Display or
Default), then press the button.
4. Press the / button to adjust the settings, then press the
ENTER button to confirm.
5. Repeat steps 3 and 4 to adjust other options. Press the
button to return to the previous menu.
6. Press the SETUP or RETURN button to exit the menu.
Default
It takes 3-5 seconds to reset the DVD settings to the factory default.
TV Display
Pan Scan
• When wide-screen video is played, this mode clips the right and left sides of the
image so that it can be viewed on a conventional screen.
• Some wide-screen DVDs that do not permit Pan Scan mode playback are
automatically played in letterbox mode (black bands that appear at the top and
bottom of the screen).
Letter Box
• When wide-screen video is played in this mode on a conventional screen, black
bands appear at the top and bottom of the screen.
Wide Screen
• This is the correct mode for playing wide-screen videos on the unit screen or other
external wide-screens.
Notes:
• The displayable picture size is preset on the DVD. Therefore the playback picture
of some DVDs may not conform to the picture size selected.
• When you play DVDs recorded in the 4:3 aspect ratio, the playback picture will
always appear in the 4:3 aspect ratio regardless of the TV display setting.
• Select Wide Screen to conform the LCD screen on the unit. Always be sure that
your TV display conforms to the actual TV in use if you connect the unit to a TV.
Wide Screen
Letter Box
Cut off when a wide-screen
video image is played.
Pan Scan
2. Input the title (2 digits) and chapter (2 digits) by pressing the number buttons. (For example: 01 02, 02 05, 02
11.) It will move to the next item automatically.
• You can use the Cursor buttons ( , , , ) to move the highlighted bar to any item, and re-enter the title and
chapter. (Press the NEXT / PREV to move to the the next / previous setup page.)
• You can use the Cursor buttons ( , , , ) to move the highlighted bar to “Clear”, “Exit”, “Start” or “Next / Prev”,
and press the ENTER button to confirm.
Clear: Delete all the input programs.
Exit: Exit memory menu and return to normal
playback.
Start: Start memory playback.
Next / Prev:Move to the the next / previous setup
page.
This owner’s manual explains the basic instructions for operating this unit. Some DVDs are produced
in a manner that allows specific or limited operation during playback. Therefore, this unit may not respond
to all operating commands. THIS IS NOT A DEFECT. Please refer to the instructions accompanying the
specific DVD in question for more information about the options available on that DVD.
“ ” may appear on the screen during operation. A “ ” means that the desired operation is not permitted
by the unit or disc.
PLAYING A DISC
Basic playback
Playing a Disc
1. Slide the ON / STANDBY switch on the top of the unit to the ON position.
See CUSTOMIZING THE FUNCTION SETTINGS before proceeding to step 2.
2. Press and hold the open knob to open the disc door.
3. Hold the disc by its sides and carefully place it onto the spindle with the label side facing up, pushing gently
until you hear a “click”.
4. Close the disc door. It takes a short while for your unit to load the disc. After loading, the unit will automatically
bring you to the main menu of the DVD or start playing the DVD.
5. If the unit does not automatically star t playing the DVD, press the PLAY button.
Pausing Playback (Still Mode)
Press the PAUSE button. To resume normal playback, press the PLAY button.
Each time you press the PAUSE button, the picture advances one frame.
Stopping Playback
Press the STOP button at the location where you want to interrupt playback. To resume playback at the
position where the disc was stopped, press the PLAY button.
If you press the STOP button twice, the unit’s memory will be cleared and pressing the PLAY button will reset
the DVD to the beginning.
Fast Forward / Fast Reverse
1. Press the SEARCH or SEARCH button when a disc is playing. Each time you press the SEARCH
or SEARCH button, the playback speed changes in the following sequence:
2. Press the PLAY button when you reach the desired point to resume normal playback.
Notes:
• The DVD player mutes sound and subtitles during reverse and forward scan of DVDs.
• The fast playback speed may differ depending on the disc.
Skip (Forward / Reverse)
• Press the NEXT button to advance chapters/tracks.
• Press the PREV button to go back to current or previous chapters/tracks.
• For an Audio CD, use the number buttons on the remote control to the desired track number.
Audio Selection
On some DVDs, the sound is recorded in two or more formats. Follow the directions below to select the preferred
language and sound system.
1. While a disc is playing, press the AUDIO button to show the current audio format number.
2. Press the AUDIO button repeatedly to select the desired audio format.
Notes:
• If only one audio format is recorded on the DVD, the number does not change.
• Some DVDs allow you to change audio selections only via the disc menu. If this is the case, press the MENU
button and choose the appropriate language on the disc menu.
• You can select different audio channels (Stereo, Mono Left, Mono Right or Mix-Mono) on an Audio CD by
pressing the AUDIO button repeatedly.
Subtitle Selection
1. While a DVD is playing, press the SUBTITLE button to display the current language setting, as shown in the
example.
2. Press the SUBTITLE button repeatedly to select the desired subtitle language. You can tur n subtitles off by
pressing the SUBTITLE button repeatedly until the “
Subtitle Off
” is displayed.
Notes:
• Some DVDs are set to display subtitles automatically, and you cannot turn them off even if you set the subtitle
function to off.
• During some scenes, the subtitles may not appear immediately after you select your desired scene.
• The number of subtitle languages recorded differs depending on the disc. If only one language is recorded,
the language does not change.
• This function can only be used for discs on which subtitles have been recorded in multiple languages.
• Some DVDs allow you to change subtitles only via the disc menu. If this is the case, press the MENU button
and choose the appropriate subtitle on the disc menu.
Angle Selection
Some DVDs contain scenes that have been shot from a number of different angles. For these discs, the same
scene can be viewed from each of these different angles.
Note: This function can only be used for discs on which scenes shot from multiple angles have been recorded.
Display Function
While the disc is playing, press the DISPLAY button repeatedly to display information on operation status.
Adjust the LCD Screen
You can adjust Brightness, Panel Display and Contrast of the LCD screen.
1. Press the VIDEO MODE button.
2. Press the / button to select Brightness, Panel Display or Contrast.
3. Press the / button to change the setting.
4. Press the VIDEO MODE button to exit the menu.
Sequence of angle shots
(Example)
1. While you are playing a DVD with different angles recorded,
press the ANGLE button to view the number of current angles
available.
2. Press the ANGLE button repeatedly to change the scene to the
next recorded angle.
• After approx. two seconds, playback will continue from the new
angle selected.
• If no button is pressed within 10 seconds, playback continues
without changing the current angle.
E - 7
Chapter Elapsed
Tt 01/03 Ch 03/12
0:13:26
Chapter Remain
Tt 01/03 Ch 03/12
0:05:42
Title Remain
Tt 01/03 Ch 03/12
0:36:08
Display Off
Subtitle 02/03:Spanish
Audio 1/3:Dolby D 2ch English
Subtitle 02/03:Spanish
Audio 1/3:Dolby D 2ch English
Subtitle 02/03:Spanish
Audio 1/3:Dolby D 2ch English
Chapter Elapsed
Tt 01/03 Ch 03/12
0:13:26
Subtitle 02/03:Spanish
Audio 1/3:Dolby D 2ch English
Chapter Remain
Tt 01/03 Ch 03/12
0:05:42
Subtitle 02/03:Spanish
Audio 1/3:Dolby D 2ch English
Title Remain
Tt 01/03 Ch 03/12
0:36:08
Subtitle 02/03:Spanish
Audio 1/3:Dolby D 2ch English
Audio 1/3:Dolby D 2ch English
Audio 1/3:Dolby D 2ch English
Title 01/03 Chapter 03/12
Title 01/03 Chapter 03/12
Title 01/03 Chapter 00/00
Title 01/03 Chapter 00/00
Clear Exit Next
1
2
3
4
5
Tt:01ch:05
Tt: ch:
Tt: ch:
Tt: ch:
Tt: ch:
6
7
8
9
10
Start
Tt: ch:
Tt: ch:
Tt: ch:
Tt: ch:
Tt: ch:
Clear Exit Next
1
2
3
4
5
Tt:01ch:05
Tt: ch:
Tt: ch:
Tt: ch:
Tt: ch:
6
7
8
9
10
Start
Tt: ch:
Tt: ch:
Tt: ch:
Tt: ch:
Tt: ch:
To Previous Page
Loading...
Need help?
General
