•QUICK START GUIDE•
Verify Identify
Wiring
Standard Wiegand
Wire Color Connection
Black Ground
Red Power +12 V
Brown Access Granted Signal (green)
Blue Not Used
Yellow Not Used
Green Wiegand Zero
White Wiegand One
Gray Not Used
Orange Tamper Switch
Wiegand & RS-485
Wire Color Connection
Black Ground
Red Power +12 V
Brown Access Granted Signal (green)
Blue RS-485 Data -
Yellow RS-485 Data +
Green Wiegand Zero
White Wiegand One
Gray Not Used
Orange Tamper Switch
Standard Serial RS-485
Wire Color Connection
Black Ground
Red Power +12 V
Brown Not Used
Blue RS-485 Data -
Yellow RS-485 Data +
Green Not Used
White Not Used
Gray Not Used
Orange Tamper Switch
Be sure to attach the black ground wire
and red power wire to the appropriate
connectors.
REVERSING POWER WIRES
VOIDS THE WARRANTY
Stealth Series Readers
