VeriFone VX 520 Instruction Manual

ITCARD • Planet Cash • Planet Pay • Planet Plus
30
FIGURE 36 PREPAID GSM – CASH-BASED PAYMENT
FIGURE 37 PREPAID GSM – EXEMPLARY PRINTOUTS
3.2.8 Return
The Return transaction is the transaction opposite of the Sales transaction, i.e. the transaction amount
is transferred (returned) to the Client’s account.
The access to the Return transaction is protected by the Administrator’s password.
1. Select the GOTÓWKA
(eng. CASH) option
2. The application connects with the Authorisation Centre and displays the result of the
transaction.
3. The application displays the „Gotówka otrzymana?” (eng. “Cash received?”) question. The confirmations are printed out
when the proper value is selected.
If the „NIE” (eng. “NO”) answer is indicated, the code is not printed out, and the transaction is cancelled
Prepaid GSM – card-based payment, transaction
accepted
Prepaid GSM – copy
printout from the menu

VeriFone VX 520 Specifications

General

Processor	400 MHz ARM11
Card Readers	Magnetic stripe, EMV chip
Operating Temperature	0°C to 50°C (32°F to 122°F)
Display	128x64 pixel backlit LCD
Connectivity	Dial-up, Ethernet
Contactless	Optional
Printer	18 lines per second
Security	PCI PTS 3.0 approved
Weight	500g
Dimensions	203 mm x 87 mm x 77 mm (8.0 in x 3.4 in x 3.0 in)
