Assembly Instructions (continued)
6
4. Attaching the Parabolic Grid Diffuser
• Remove grid diffuser from protective
plastic bag
• Insert plastic pegs at bottom of
grid diffuser into openings near
bulb socket
• Snap tab into place
5. Plug lamp into outlet and turn on; if bulb
does not illuminate instantly, please refer
to the troubleshooting section of this manual.
Assembly Instructions
5
Read Instructions Carefully Before
Assembly:
1. Remove lamp from box and packaging.
Remove red plastic protective pieces
from lamp shaft. NOTE: Please save
original packaging for repacking should
you need to return the product.
2. Set lamp base on the floor and insert
the lamp shaft over the base support
part until the screw holes line up as
shown in Fig.1. Insert the screw using
the tightening tool and turn clockwise
to tighten.
3. Attach the lamp head gooseneck to
the shaft, tucking the wire into the shaft,
until the screw holes line up as shown
in Fig.1. Insert the screw using the
tightening tool and turn clockwise to
tighten. Should you have difficulty lining
up the base or head screw holes, refer
to the troubleshooting section of this
manual.
Close-up of screw hole
in the lamp base
Fig. 1
DO lift your lamp by the shaft
DO NOT lift the lamp by
the gooseneck
